Group 8 Job editor Page 279
Release R2.0 LEIBINGER JET3
IMPORTANT
There will be only on <Replacement> tab be displayed even if there
are a <Date/Time> object AND a <Counter> object used in the
<Content> display field (2). The settings on the <Replacement> tab
will affect the <Date/Time> object as well as the <Counter> object.
Extern text object (6)
Pushing the <Extern Text> button (6) will insert a {e} symbol (15) at the current
cursor position within the <Content> display field (2). There will also be displayed
an additional tab on the tab bar of the <Object Settings> dialog box:
Extern text tab (14)
On the <Extern Text> tab the content of the placeholder {e} is configured.
INFORMATION
For details about configuring extern text objects please see chapter
Extern Text for details.
FNC1 function (7)
Pushing the <FNC1> button (7) will insert a {f} symbol (16) at the current cursor
position within the <Content> display field (2).The function <FNC1> is a special
code used with GS1 bar codes .The <FNC1> control character identifies data with
Application Identifiers (AI). The <FNC1> control character is followed by an
Application Identifier (AI) number which provides a bar code reader with information
about the following data. The <FNC1> control character represents the ASCII
character 207 (dec.).
Example:
Code: [FNC1] 21 12345 [FNC1] 11 090101 17 100101
21: Serial number. The following number is considered as a serial number
10: Lot number data. The following number is considered as a lot number
Field Sep (GS) (8)
Pushing the <Field Sep (GS)> button (8) will insert a {g} symbol (17) at the current
cursor position within the <Content> display field (2).The function <Field Sep
(GS)> is a special code used with PPN bar codes.
