Group 8 Job editor Page 280
Release R2.0 LEIBINGER JET3
The PPN (pharmaceutical product number) specifications require a field separator
between data elements. Actually the field separator represents the ASCII character
29 (dec.).
Figure 150
Bar codes: Insert objects
1 – <Bar code> tab
10 – <Date/Time> tab
2 – <Content> display field
11 – {t} symbol for <Date/Time> object
3 – <Insert> section
12 – <Counter> tab
4 – <Date/Time> button
13 – {c} symbol for <Counter> object
5 – <Counter> button
14 – <Extern Text> tab
6 – <Extern Text> button
15 – {e} symbol for <Extern Text> object
7 – <FNC1> button
16 – {f} symbol for <FNC1> character
8 – <Field sep (GS)> button
17 – {g} symbol for <Field sep (GS)> character
9 – <Replacements> tab
17
6
6
10
9
11
4
1
2
10
2
3
9
4
6
7
5
1
8
3
12
9
4
14
6
14
15
13
5
12
9
16
7
17
6
5
6
