8.7.1.4.3 Bar code settings: <Inverse> function
It is possible to print all kind of barcodes inverted. To change a barcode into an
inverted barcode you have to check the respective checkbox in the barcode menu.
Differences between non-inverted and inverted barcode
Barcode setting dialog box – “inverse”
checkbox not selected
Barcode setting dialog box – “inverse”
checkbox selected
Results with a matrix code and a bar code
Non-inverted barcode in the editor
Inverted barcode in the editor
Non-inverted barcode in the WYSIWYG
window
Inverted barcode in the WYSIWYG
window
Additionally there is an <Inverse> function available on the <Global settings> tab
of the <Object settings> dialog box. Therefore there are 2 <Inverse> functions
with 4 possible options.
Tick off for inverted bar codes
