Group 8 Job editor Page 294
Release R2.0 LEIBINGER JET3
8.7.3.1.1 Number of digits
The setting defines the number of digits of the counter. The maximum input is 10
digits. The set value is shown on the accordant display field.
8.7.3.1.2 Start value
The setting defines the start value of the counter. The maximum input is 10 digits.
After reaching the end value the counter will be reset to the start value.
The set value is displayed on the accordant display field.
8.7.3.1.3 Initialization value
The setting defines the initialization value of the counter. The maximum input is 10
digits.
That means if the job is started or loaded for the first time, it is first counted from
the initialization value to the end value. Afterwards it is then always counted from
the start value to the end value.
The set value is shown on the accordant display field.
Figure 156
Counter settings (Initialization value)
Counter settings (Initialization value)
Example:
Initialization value
End
value
Start
value
