Leibinger Jet 3 - Page 45

Group 5 Transport/Start up Page 43
Release R2.0 LEIBINGER JET3
Discharging the ink into a service tray
Fire hazard
Explosion
hazard
Electrostatic-
sensitive
device
Cleaning the print head
Fire hazard
Explosion
hazard
Electrostatic-
sensitive
device
Print head
Service tray
Leibinger
Cleaning station
Ground cable
Connect print head
with service tray
Ground cable
Connect print head
with service tray
