Group 5 Transport/Start up Page 44
Release R2.0 LEIBINGER JET3
5.4 Starting
(Commissioning)
For a safe transport some hydraulic components are supplied with transportation
protection (cable ties) and the reservoir tanks are evacuated. The following steps have to
be carried out before the initial operation
 Remove the transportation protection (cable ties) (Step 1)
 Fill the reservoir tank (Step 2)
 Carry out the function <Filling Routine> (Step 3)
5.4.1 Remove transportation safety devices
(Step 1)
The pumps and valves of the hydraulic system are secured with cable ties. These
have to be absolutely removed.
Proceeding:
 Dismantle the backplane of the hydraulic cabinet (1) by loosing the fixing screws
(2).
ATTENTION
The cable tie at the main filter (3) should not be removed!
 Remove the transportation protection (cable ties).
 Now attach the backplane of the hydraulic cabinet again with the according fixing
screws.
