Group 5 Transport/Start up Page 49
Release R2.0 LEIBINGER JET3
5.4.3 Carry out filling routine
(Step 3)
After filling the consumables you have to carry out the filling routine.
Proceeding:
Figure 10
Filling routine (Step 1)
1 – TFT-Touch-Display
5 – Tab <Spec. func. /Tools>
2 – Message <Initialization>
6 – Button <Fill up Routine>
3 – Message <Emergency Shutdown
7 – Message <Fill up Routine>
4 – Button <OK>
8 – Button <next>
1
3
2
4
5
7
6
8
