Leica GPS1200 User Manual

Tools... GPS1200 173
23.3 Upload System Files...
Description System file uploads are possible from the CompactFlash card to a particular memory
device, depending on the type of file chosen to be uploaded. These files are stored
in the \SYSTEM directory of the memory device.
)
SmartAntenna must always be connected to RX1250 when uploading the firmware.
Connect SmartAntenna and RX1250 via cable.
Uploading the firmware takes some time.
Access Select Main Menu: Tools...\Upload System Files...\XX.
Way of working
step-by-step
Next step
CONT (F1) uploads the selected system file.
Step Description
1. Select the memory device to upload the system file from.
2. Select the memory device to upload the system file to.
3. Select the system file to upload.

Leica GPS1200 Specifications

General

GPS L1/L2	Yes
GLONASS L1/L2	Yes
SBAS	Yes
Update Rate	Up to 20 Hz
Protection Rating	IP67
Frequency	L1, L2
Communication	RS232, Bluetooth
