Leica T-Scan 5 User Manual

Device Range
Stand-off (mid working distance) 150 mm
Working range (measuring depth) ±50 mm
Scan width (at Stand-off) ca. 100 mm
Measurement Camera Value
Sampling rate of distance measure-
ment
max. 210 kHz
Line frequency 160 Hz (at 100% scan width)
max. 330 Hz (at 40% scan width)
Minimum point density 0.075 mm at 150 mm distance
Measurement Range Range
T‑Scan 1.5 - 25 m (depending on type of
Laser Tracker)
Rotation Angles Range
Roll (rotation around X-axis) ±360°
Pitch (rotation around Y-axis) ±46°
Yaw (rotation around Z-axis) ±46°
IP Address AMS Net ID
10.168.2.200 10.168.2.200.1.1
•
FCC Part 15 (applicable in US)
Hereby, Leica Geosystems AG, declares that the product/s
is/are in compliance with the essential requirements and
other relevant provisions of the applicable European Direc-
tives. The declaration of conformity can be consulted at
http://www.leica-geosystems.com/ce.
Scan Field
Scan performance
Range
Network settings
T‑Scan controller
Conformity to
national regula-
tions
38 Technical Data
