LELY HIBISCUS 805 Master - Dtechnical Details

E-20
D TECHNICAL DETAILS
All details are without engagement and may be altered
without prior notice.
HIBISCUS
®
725 Classic
725 Classic
(SA)
725 Master 805 Master
Working width 6,85 / 7,25 m 7,55/7,95 m
Transport width 2,85 m
Transport height 3,95 m 3,50/3,95 m 3,75/4,30 m
Transport length
(depending on linkage)
5,75 / 6,10 m 5,75 m
Diameter of rotor(incl. tine arms) 3,20 m 3,50 m
Number of tine arms x tines 2 x 11x4 double tines
Swath width 1,20 - 1,60 m
Linkage
Draw hook or
category II
Category II
Hydraulic connection
1 double acting valve with floating position
(max. oil pressure 21,0 MPa (210 bar))
PTO output 350 - 475 r.p.m., max. 540 r.p.m.
Overload safety 2x K33 slip clutch
Operating speed max. 12,5 km/h
Oil gearbox
rotor housing
1,7 l GX85W-140
6,0 l GX85W-140
1,7 l GX85W-140
-
Tire size
transport
rotors
10,0/75-15,3 8 ply
16/6,8-8 6 ply
Power required
35 kW
(48 HP)
38 kW
(52 HP)
Weight approx. 2.100 kg 2.280 kg 2.350 kg 2.500 kg
Supplement D
