Index

Soldering point.

Male connector.

Female connector.

M/F faston connector.

Test point.

Supply voltage. Logic supply ground.

Analog supply ground.

Chassis ground.

Earth ground.

Flag joined with one or more flags

GENERALMUSIC S.p.A. Sales Division: 47842 S.Giovanni in Marignano (RN) ITALY - Via delle Rose, 12

Phone +39(0)541/959511 - Fax +39(0)541/957404 - Internet: www.generalmusic.com

Technical Specifications.2

Test Preocedures & Adjustments.3

Schematic Diagrams.

PCB Layouts.5

Passive Version Schematic Diagrams.6

Spare Part List. 7

with the same signal name inscribed.

ATTENTION Observe precautions when handling electrostatic sensitive devices.

Notice

Service must be carried out by qualified personnel only. Any tampering carried out by unqualified personnel during the guarantee period

will forfeit the right to guarantee.

For a correct operation of the instrument, after having switched off, be careful to wait at least 3 seconds before switching on again.

To improve the device's specifications, the schematic diagrams may be subject to change without prior notice.

All components marked by this symbol have special safety characteristics, when replacing any of these components use only

manufacturer's specified parts.

The (µ) micro symbol of capacitance value is substituted by U.

The (

Ω) omega symbol of resistance value is substituted by E.

The electrolytic capacitors are 25Vdc rated voltage unless otherwise specified.

All resistors are 1/8W unless otherwise specified.

All switches shown in the "OFF" position. All DC voltages measured to ground with a voltmeter 20KOhm/V.

✔

✒

☎

SERVICE MANUAL

code 270292

d400 Dsp powered loudspeaker system

x300 Lightweight passive loudspeaker

LEM d400 - Page 18

Other manuals for LEM d400
