Cursor field:
OFF: Reference variable for the LED is active energy
ON: Reference variable for the LED is reactive energy
OFF: no GPS telegram received
FLASHING: GPS telegram received
ON: Valid GPS telegram received -> clock engaged
OFF: No communication on the RS232 interface
ON: Communication on the RS232 interface
OFF: Power reserve for the device clock not depleted
ON: Power reserve for the device clock depleted
OFF: There is no fatal device fault
ON: There is a fatal device fault
The individual pieces of energy and operation information are displayed cyclically (approximately 10
seconds) as shown in table 4.2:
Table 4.1: Cursor arrows definition
