05November2020/V1.0 Page 11/33
4. Displays and parameterization, data interfaces
4.1 Display screen and operating display
Display of detected mains system on the display screen (possible values):
12 → 16.7 Hz measurement of current on channel 2 (only possible with AC or ACDC version)
52 → 50 Hz measurement of current on channel 2 (only possible with AC or ACDC version)
62 → 60 Hz measurement of current on channel 2 (only possible with AC or ACDC version)
D4 → DC measurement of current on channel 4 (only possible with ACDC version)
D2 → DC measurement of current on channel 2 (only possible with DC, DCDC or DCDCDC version)
D 3 → DC measurement of current on channel 3 (only possible with DCDC or DCDCDC version)
D 4 → DC measurement of current on channel 4 (only possible with DCDCDC version)
