Table 4.5: Status word bit coding
The header is followed by sets of nine (for standard version) measuring values until the next event
generates a new header.
In the standard version the following values are recorded in the load profile:
• C.1.9 Consumption Point ID (according to EN 50463-1:2017), a max. 32 ASCII characters
comprehensive text string
• C.5.1 Status of this load profile entry ("Quality flag" according to EN 50463-3),
three bytes in the following code:
Bit
hexadecimal
coding
Meaning
Usage in load
profile
Usage in log
(P.98)
*1 depending on
configuration
b31
80000000
AC over voltage
X
*1
b30
40000000
DC over voltage
X
*1
b29
20000000
AC under voltage
X
*1
b28
10000000
DC under voltage
X
*1
b27
08000000
AC voltage below startup level
X
*1
b26
04000000
DC voltage below startup level
X
*1
b25
02000000
AC voltage above U
min2
X
*1
b24
01000000
DC voltage above U
min2
X
*1
b23
…
b18
-
always 0 (reserved for future use)
b17
00020000
Change of the supply system
(Traction Type - C.5.3)
X
b16
00010000
Change of the Consumption Point ID (C.1.9)
X
b15
00008000
Status word has been recorded before the last
clock synchronization
X
X
b14
00004000
Load profile memory was completely deleted
X
X
b13
00002000
Logbook was completely deleted
X
b12
…
b9
-
always 0 (reserved for future use)
b8
00000100
(At least) one configuration variable was
changed by setting
X
b7
00000080
Failure of the supply voltage of the EM4TII+
X
X
b6
00000040
recovery of the supply voltage of the EM4TII+
(always captured in the load profile
synchronously to capture periods)
X
X
b5
00000020
device clock was set
X
X
b4
-
always 0 (reserved for future use)
b3
00000008
season change occurred
(summer time to winter time or vice versa)
X
b2
00000004
Measurement period are incomplete (due to
asynchronous start of period)
X
b1
00000002
power reserve of the device clock is depleted
X
b0
00000001
fatal device error (legal metrological error)
X
X
