LEMKEN EurOpal - User Manual

Questions and Answers

M
Mary PayneJul 27, 2025
What to do if the plough frame turns but the turnover ram switches over prematurely on my LEMKEN Farm Equipment?
- D
  Dennis MooreJul 27, 2025
  If the plough frame of your LEMKEN Farm Equipment turns, but the turnover ram switches over before reaching the half-turned position, causing the plough frame to turn back again, it could be due to a few reasons: * The pre-adjusted switchover pressure might be too low. You can increase it by fitting additional washers (U), where one washer equals a 10 bar increase in switch-over pressure. * The inner turnbuckle might be too short. Try lengthening it. * The bearing of the turnover device might be damaged. In this case, check the bearings and replace them if necessary.
S
Sandra WyattAug 1, 2025
What to do if the memory ram doesn't open or close on my LEMKEN Farm Equipment?
- M
  Michele RodriguezAug 1, 2025
  If the memory ram on your LEMKEN Farm Equipment does not open or close, it's because the throttle bores of the threaded throttle in the memory ram are blocked. To resolve this, screw out the threaded throttles out of the ram connections using a circlip tong and clean them. Note that connection (S) has no throttle.
M
Matthew BlairAug 4, 2025
Why does the plough frame start turning prematurely on my LEMKEN Farm Equipment?
- S
  Shaun FieldsAug 4, 2025
  If the plough frame on your LEMKEN Farm Equipment starts turning before the Memory ram or swing-in ram are fully swung in, it's likely due to high friction of the frame pivot bolts. Carefully grease the pivot bolts according to the maintenance table.
E
Edgar RogersAug 9, 2025
What to do if the front furrow width changes during work with my LEMKEN Farm Equipment?
- P
  Paul GillespieAug 9, 2025
  If the front furrow width of your LEMKEN Farm Equipment changes during work, it's likely that the piston seal of the swing-in ram or Memory ram is leaking. The suggested solution is to replace the piston seal.
R
Robert BrownAug 13, 2025
Why does the plough frame on my LEMKEN Farm Equipment stop in the middle position?
- C
  Carla TuckerAug 13, 2025
  If the plough frame of your LEMKEN Farm Equipment turns up to the middle position and stops, it means that the required switchover pressure for the turnover ram has not been reached by the tractor hydraulics. To solve this: a) Reduce the pre-adjusted switchover pressure by removing the washers (U). Removing one disc means a pressure reduction of approximately 10 bar. The washers (U) are located behind the plug (V). b) Check the hydraulic assembly of the tractor and maintain it if required.
R
Robert MitchellAug 18, 2025
What to do if the turnover ram switches over without turning the plough frame on my LEMKEN Farm Equipment?
- M
  Ms. Heather FergusonAug 18, 2025
  If the turnover ram on your LEMKEN Farm Equipment switches over without turning the plough frame, it could be due to: a) The pre-adjusted turnover pressure being too low. Increase the pre-adjusted switchover pressure by adding an additional washer (U). b) The cone or its seat of the switchover valve is damaged and leaky. Replace the hydraulic ram.
M
Marie GrayAug 22, 2025
How to fix rattling during the first turning phase of my LEMKEN Farm Equipment plough?
- T
  Teresa MeyerAug 22, 2025
  If your LEMKEN Farm Equipment plough turns with a rattling sound during the first turning phase, it's because the plough frame runs forward, creating a vacuum in the hydraulic ram. To fix this: a) Lengthen the inner turnbuckle. b) Fit a smaller throttle to the connection (T) of the turnover ram.

Summary

Safety Instructions

General Safety Instructions

General safety guidelines for operating the implement safely and responsibly.

Attached Implements Safety

Specific safety considerations when attaching or detaching implements to the tractor.

Hydraulic Equipment Safety

Safety precautions related to hydraulic systems and connections.

Tyre Safety Precautions

Safety advice concerning the maintenance and handling of implement tyres.

Maintenance Safety

Safety measures to be followed during maintenance and cleaning operations.

Warning Stickers

Warning Sticker General Instructions

Importance of warning stickers for safe operation and their replacement.

Meaning of Warning Stickers

Explains the meaning of various warning symbols and labels on the implement.

Warning Sticker Placement

Illustrates the locations of warning stickers on the implement for clear visibility.

Tractor Preparation

Tyre Preparation and Ballast

Proper tyre pressure and ballast for tractor operation with the implement.

Lift Rod Adjustment

Adjusting lift rods to ensure equal length for proper linkage.

Linkage Chain;Sway Block Adjustment

Adjusting linkage chains or sway blocks for free movement during ploughing.

Hydraulic Control Settings

Setting tractor hydraulics to 'Draft' or 'Mixed' Control for operation.

Required Hydraulic Equipment

Specifies the necessary spool valves and return pipe connections for the implement.

Axle Load Management

Managing tractor axle loads and front ballast for safe operation.

Using the Plough

Initial Setup and Adjustments

Recommendations for initial adjustments before field operation.

Adjustment Centre Optiquick Turnbuckle

Adjusting the outer turnbuckle for compact transport and field alignment.

Depth Control Wheel Adjustment

Adjusting the depth control wheel for desired working depth.

Turnover Operation Clearance

Ensuring sufficient clearance during plough turnover operations.

Skimmer Setting and Adjustment

Setting skimmers for optimal depth and lateral position relative to plough bodies.

On-Field Adjustments

Final adjustments on the field for top link, pitch, and depth control.

Three Point Attachment Guidelines

Ensuring correct category of three-point linkage for tractor and implement.

Drawbar Height Adjustment

Adjusting the drawbar height for optimal implement entry and turning.

Attaching and Detaching the Plough

Plough Attaching Procedure

Step-by-step guide for attaching the plough to the tractor.

Plough Detaching Procedure

Step-by-step guide for detaching the plough from the tractor.

Turning the Plough Frame

Turnover Frame General Instructions

Information on the turnover device and its various versions.

Onland Use (Europal OF)

Onland Use General Instructions

Explains onland and in-furrow operation modes for specific models.

Convert to Onland Operation

Steps to convert from in-furrow to onland operation.

Convert to Furrow Operation

Steps to convert from onland to in-furrow operation.

Adjustment Centre Optiquick (F-Operation)

Adjustments for front furrow width in F-operation mode.

Adjustments

Front Furrow Width Adjustment

Adjusting the front furrow width using turnbuckle or hydraulic controls.

Tractor-Plough Alignment Adjustment

Aligning the tractor and plough for optimal performance.

Plough Angle Adjustment

Adjusting the angle of the plough legs for vertical alignment.

Working Depth Adjustment

Adjusting the working depth using tractor hydraulics and depth wheel.

Hydraulic Frame Swing-in Assembly

Description and operation of the hydraulic frame swing-in assembly.

Hydraulic Front Furrow Width Adjustment (Memory Ram)

Using a memory ram for hydraulic front furrow width adjustment.

Plough Body Adjustments

Adjusting pitch, working width, and tail pieces of plough bodies.

Skimmer Adjustments

Setting and adjusting skimmers for optimal performance.

Disc Coulter Adjustments

Adjusting disc coulters for depth, lateral distance, and swivelling.

Soil Loosener Adjustments

Adjusting subsoilers for working depth and fitting subsoiler shares.

Depth Control;Transport Wheel

Fitting, adjusting depth, and managing air pressure for depth wheels.

Overload Safety Devices

Shearbolt Device

Description and replacement of shearbolts for overload protection.

Semi-Automatic Overload Safety Device HX

Details of the semi-automatic overload safety mechanism.

Automatic Non-Stop Overload Safety Device

Information on the automatic non-stop overload safety system.

Hydraulic Non-Stop Overload Safety Device HydriX

Operation and adjustment of the hydraulic non-stop overload safety device.

Trouble Shooting

Hydraulic Equipment Issues

Common hydraulic malfunctions and their remedies.

Penetration, Depth, and Slippage Issues

Troubleshooting issues related to plough penetration and tractor slippage.

Other Troubleshooting Issues

Troubleshooting common issues like shearbolt breakage.

Transport on Public Roads

Warning Boards and Lighting

Requirements for warning boards and lighting for road transport.

Transport Speed Limits

Maximum allowed driving speed during transport.

Technical Data

Technical Overview

Technical specifications and model overview of the ploughs.

Allowed Tractor Power Range

Recommended tractor power range for different plough models.

Plough Weight Specifications

Weight specifications for various plough configurations.
