LENCO LED-3213 - Keys and Interfaces

3
The design and specication takes actual
products as the standard
1.4 Keys and Interfaces
LE D COLOR TV
󱯣 󱯤
󱯥
󱯧
󱯨 󱯩
󱯦
23
22
VIDEO R
L
AV I N
RF IN
PC(VGA)
PC AUDIO
EARPHONE
HDMI3
USB
HDMI1 HDMI2
COAXIAL
SCART
YPbPr IN
CI
24
25
1. Remote sensor window
2. Power indicator
3. Speaker
4.
Power switch
5.
Menu key
6.
Program “ + ” key
7. Program “ ” key
8. Volume “
+
” key
9. Volume “
-
” key
10.
Source key
1
1.
Standby
key
12.
Power plug input
13. AV input
20 .
HDMI1
19.EARPHONE output
17.RF input
21.HDMI2
15.PC AUDIO input
24.USB
25.Coaxial
14.Scart input
16.PC(VGA) input
22.HDMI3
-
18.YPbPr IN
23.CI card
