LENCO SCD-24 User Manual

GB 5
CLEANING THE UNIT
Do not use volatile chemicals on this unit. Clean by lightly
wiping with a soft cloth.
IMPORTANT NOTE
If an abnormal display indication or an operating problem
occurs, disconnect the AC power cord and remove the
batteries. Wait at least 5 seconds, then reconnect the AC
power cord or reinstall the batteries.
WARNING
Should the CD door be opened before the reading of the CD
is completed, a jamming noise may occur. This is resolved
by closing the CD door.
CLEANING A CD
If the CD skips or will not play , the disc may need cleaning
. Before playing, wipe the disc from the centre out with a
cleaning cloth. After playing, store the disc in its case.
MAINTENANCE
CLEANING THE CD LENS
If the CD lens is dusty, clean it with a brush-blower. Blow
several times on the lens and remove the dust with the
brush. Finger prints may be removed with a cotton swab
moistened with alcohol.
SPECIFICATIONS
CD
S/R ratio: 58 dB
Sample frequency: 44.1 kHz 8x oversampling
Quantization: 1 bit DA converter
Laser wavelength: 790 nm
Radio
Frequency range: FM: 87.5 - 108Mhz
Antenna: Telescopic
General
Input voltage: AC 230V- 50Hz
Power consumption: 13.5W
Output power: 1W + 1W (RMS)
Speaker size: 3"
Speaker impedance: 8 Ohm
Phones output: 3.5mm Jack
Battery specication: 6x 1.5V LR14/C/UM2
Dimensions: 224 x 234 x 126mm (wxdxh)
Weight: 1.45Kg
Commaxx International reserves the right to change the contents of this document without notice.

LENCO SCD-24 Specifications

CD Section

channels	2 channels
S / N ratio	60 dB
sampling frequency	44.1 kHz
pick up wave length	790 nm

Radio Section

tuning ranges	FM 87.5 - 108 MHz
antennas	FM Rod antenna

General Specifications

output power	1 W + 1 W (RMS)
power consumption	13.5 W
power source AC	230V ~ 50Hz

Weight and Dimensions

dimensions	224(L) x 234(D) x 126(H)mm
weight	2.4 KGS
