LENCO SCD-24 User Manual

FOR BETTER RECEPTION
FM
COMPACT DISC PLAYBACK
GB 3
1 . Set to CD
2 . Open the CD door by pushing
CD Door Open / Close button.
3. Insert a disc with the label side facing up.
4 . Close the CD door.
The disc will rotate and the total
tracks of the disc will show on
the display.
TO SKIP TO THE BEGINNING OF A TRACK
• Press either one of the skip buttons according to the desired skip direction.
• Play/back resumes from the selected track.
• When the button is pressed once during play, the previous track starts again.
• When the button is pressed once during play, the next track plays.
SEARCHING FOR A PASSAGE WITHIN A TRACK
• Keep the or button pressed during playback,
and release the button as soon as you recognise the desired
passage. Then normal CD playback will resume from this point.
TO STOP PLAYBACK
Press the STOP button and the display shows the total
tracks of the disc.
NOTE : 1. FM stereo LED indicator lights if receive FM stereo broardcast and the MODE switch set on "FM STEREO".
2. When too much noise is heard during FM STEREO reception, set MODE switch to FM mono.
AFTER LISTENING
Set the FUNCTION selector to OFF.
5. Press the Play / Pause button.
Track number " 01 " & " PLAY " will
be shown.
CD display
PLAY
PLAY
TO INTERRUPT PLAYBACK
Press the Play/Pause button and the symbol
" PLAY " will be ashed.
Press the button again to resume playback.
CD display
Unit will be automatically o󰀨 at about 15 mins without any operation (in stop mode / CD door open).
After auto o󰀨, slide the FUNCTION selector to OFF position and then slide to RADIO / CD position for listening.
FUNCTION
CD

LENCO SCD-24 Specifications

CD Section

channels	2 channels
S / N ratio	60 dB
sampling frequency	44.1 kHz
pick up wave length	790 nm

Radio Section

tuning ranges	FM 87.5 - 108 MHz
antennas	FM Rod antenna

General Specifications

output power	1 W + 1 W (RMS)
power consumption	13.5 W
power source AC	230V ~ 50Hz

Weight and Dimensions

dimensions	224(L) x 234(D) x 126(H)mm
weight	2.4 KGS
