IFU-0002 Lenire User Manual Version 1.0Page 48
Chapter 23 - Environmental Operating Conditions
Lenire should only be used in environments between 5 and 40 degrees
Celsius, relative humidity between 15% and 93%, and atmospheric pressure
of between 700 and 1060 hPa. This precludes the use at altitudes above
3000m, unless traveling in an airplane that has the cabin pressurised.
Chapter 24 - Radio Frequency (RF) Specifications
The Lenire Controller contains a Bluetooth wireless radio module. Its
specifications are as follows:
SPECIFICATION DESCRIPTION
Frequency Band 2.4 GHz to 2.4835 GHz
Modulation 8 DPSK, PI/4 DQPSK, GFSK
Operating Range 20m to 30m
RF Sensitivity 0.1% BER at -88dBm
Eective Radiated Power (ERP) <4dBm (2.5 mW)
Bluetooth Class 2
