80MGF WITH EGC−2 COOLING SEQUENCE OF OPERATION
YES
THERMOSTAT CALLS FOR COOLING.
LED: Slow flash rate.
REMAINS UNCHANGED THROUGHOUT COOLING CYCLE.
NO
COMPRESSOR CONTACTOR AND SYSTEM FAN
ENERGIZED AT COOLING SPEED AFTER
1 SECOND DELAY. ACC TERMINAL ENERGIZED.
THERMOSTAT OPENS.
COMPRESSOR OFF.
SYSTEM FAN AND ACC TERMINAL OFF AFTER
0 SECONDS.
80MGF WITH EGC−2 MANUAL CONTINUOUS FAN SEQUENCE OF OPERATION
CONTINUOUS FAN SELECTION MADE AT THERMOSTAT.
CONTROL ENERGIZES SYSTEM FAN AT HEAT SPEED.
ACC TERMINAL ENERGIZED.
THERMOSTAT CALLS FOR HEAT.
LED: Slow flash rate.
REMAINS UNCHANGED THROUGHOUT SEQUENCE.
THERMOSTAT CALLS FOR COOLING.
SYSTEM FAN REMAINS ON HEATING SPEED AFTER
SELECTED DELAY. ACC TERM. REMAINS ENERGIZED.
SYSTEM FAN SWITCHED TO COOLING
SPEED. ACC TERMINAL REMAINS ENERGIZED.
SYSTEM FAN SWITCHES TO CONTINUOUS SPEED
AND ENERGIZES ACC TERMINAL. BOTH REMAIN ON
UNTIL CONTINUOUS FAN IS SWITCHED OFF AT THERMOSTAT.
YES NO
THERMOSTAT OPENS.
THERMOSTAT OPENS.
SYSTEM FAN SWITCHED OFF AFTER DELAY.
ACC TERMINAL DE−ENERGIZED.
HTG ACC. TERM. ENERGIZED
WITH COMB. AIR BLOWER.
