Page 5
FIGURE 1
VENT ADAPTER
CABINET TOP
80UHG
CABINET
CABINET
BOTTOM
HEAT EXCHANGER
ASSEMBLY
BURNER
ASSEMBLY
BLOWER ASSEMBLY
COMBUSTION AIR
INDUCER
FLUE BOX
SECONDARY
LIMITS
FRONT ACCESS
PANEL
DOOR INTERLOCK SWITCH
CONTROL
BOARD
TRANSFORMER
PROVE
SWITCH
80UHG PARTS IDENTIFICATION
FIGURE 2
HEAT EXCHANGER
COMBUSTION AIR INDUCER
MANIFOLD
ROLLOUT SWITCH (2)
COMBUSTION AIR
PROVE SWITCH
GAS VALVE
BURNERS
COLLECTOR
PRIMARY LIMIT
Front
Right
Top
Bottom
Left
Back
HEATING COMPONENTS (shown in horizontal position)
