507270-03Page 52 of 60 Issue 1917
A93UH1D / 92G1UH 070*B12 Performance (Less Filter)
External
Static
Pressure
in. w.c.
Air Volume / Watts at Various Blower Speeds
High Medium-High Medium-Low Low
cfm Watts cfm Watts cfm Watts cfm Watts
0.00 1615 680 1355 570 1140 480 1030 400
0.10 1565 660 1365 545 1150 465 1020 385
0.20 1535 630 1340 525 1150 440 1025 375
0.30 1440 600 1300 500 1110 420 1000 350
0.40 1405 570 1255 470 1075 400 975 345
0.50 1340 535 1200 445 1045 380 945 330
0.60 1255 500 1125 420 995 355 875 310
0.70 1165 475 1080 395 935 335 820 290
0.80 1060 455 990 365 870 315 750 265
0.90 955 425 895 345 750 285 660 245
A93UH1D / 92G1UH 090*C12 Performance (Less Filter)
External
Static
Pressure
in. w.c.
Air Volume / Watts at Various Blower Speeds
High Medium-High Medium-Low Low
cfm Watts cfm Watts cfm Watts cfm Watts
0.00 1620 745 1340 620 1130 500 965 405
0.10 1610 720 1335 595 1135 490 975 395
0.20 1565 695 1335 565 1145 465 970 385
0.30 1525 665 1300 555 1135 455 970 370
0.40 1485 635 1295 520 1110 435 960 355
0.50 1430 600 1260 495 1090 405 940 345
0.60 1365 570 1210 475 1035 390 900 330
0.70 1295 535 1155 445 995 365 860 305
0.80 1200 505 1065 415 930 340 745 270
0.90 1060 460 955 375 820 305 695 260
A93UH1D / 92G1UH 090*C16 Performance (Less Filter)
External
Static
Pressure
in. w.c.
Air Volume / Watts at Various Blower Speeds
High Medium-High Medium-Low Low
cfm Watts cfm Watts cfm Watts cfm Watts
0.00 2025 900 1690 780 1395 645 1200 540
0.10 1995 880 1705 760 1390 635 1205 525
0.20 1925 835 1675 715 1405 605 1205 505
0.30 1850 795 1640 680 1400 580 1170 490
0.40 1790 760 1575 645 1395 560 1170 475
0.50 1700 725 1540 625 1350 535 1140 450
0.60 1610 690 1455 580 1295 505 1100 430
0.70 1540 645 1365 550 1225 480 1030 405
0.80 1415 615 1265 510 1125 445 980 385
0.90 1270 565 1165 470 1060 420 900 350
NOTE: All air is measured external to unit without lter (lter not furnished - eld provided)
