A95UH1D / 95G1UH 110*C20 Performance (Less Filter)
External
Static
Pressure
in. w.c.
Air Volume / Watts at Various Blower Speeds
Bottom Return Air, Side Return Air with Optional Return Air Base,
Return Air from Both Sides or Return Air from Bottom and One Side.
Single Side Return Air - Air volumes in bold require eld fabricated
transition to accommodate 20 x 25 x 1 in. air lter in order to maintain proper
air velocity.
High Medium-High Medium-Low Low High Medium-High Medium-Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 2370 1330 2230 1100 2000 910 1735 745 2360 1320 2260 1085 1965 905 1745 745
0.10 2350 1295 2205 1085 1970 890 1730 735 2330 1285 2180 1070 1945 890 1715 735
0.20 2265 1280 2135 1070 1890 875 1730 720 2255 1250 2075 1045 1885 880 1695 725
0.30 2190 1230 2050 1040 1785 850 1685 705 2150 1210 2060 1020 1880 855 1645 710
0.40 2090 1190 1945 995 1755 830 1665 695 2015 1180 1970 990 1795 830 1610 695
0.50 2000 1160 1880 955 1685 815 1640 685 1995 1145 1900 955 1775 805 1555 680
0.60 1935 1135 1770 930 1540 780 1590 660 1920 1110 1785 910 1695 775 151 645
0.70 1805 1085 1720 895 1480 750 1505 630 1780 1070 1710 885 1590 745 1440 630
0.80 1730 1065 1590 855 1405 720 1455 610 1680 1045 1570 845 1520 710 1350 610
0.90 1645 1010 1520 840 1340 705 1400 595 1595 1010 1540 830 1445 695 1315 600
A95UH1D / 95G1UH 135*D20 Performance (Less Filter)
External
Static
Pressure
in. w.c.
Air Volume / Watts at Various Blower Speeds
Bottom Return Air, Side Return Air with Optional Return Air Base,
Return Air from Both Sides or Return Air from Bottom and One Side.
Single Side Return Air - Air volumes in bold require eld fabricated
transition to accommodate 20 x 25 x 1 in. air lter in order to maintain proper
air velocity.
High Medium-High Medium-Low Low High Medium-High Medium-Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 2445 1400 2275 1205 1985 925 1695 755 2415 1390 2240 1165 1905 915 1655 755
0.10 2410 1370 2230 1120 1950 915 1685 745 2390 1365 2210 1125 1890 905 1640 745
0.20 2350 1315 2170 1100 1890 900 1665 740 2335 1335 2140 1095 1840 890 1570 735
0.30 2250 1285 2110 1075 1820 880 1610 725 2310 1305 2040 1060 1760 860 1500 720
0.40 2150 1245 1970 1030 1750 855 1565 705 2170 1245 1965 1025 1685 835 1480 705
0.50 2030 1200 1900 995 1710 830 1510 685 2065 1215 1905 995 1625 815 1425 685
0.60 1950 1170 1795 955 1645 800 1435 670 1950 1175 1830 980 1530 785 1365 670
0.70 1870 1130 1690 915 1560 780 1410 655 1770 1125 1750 940 1435 755 1305 650
0.80 1740 1100 1520 895 1455 745 1280 620 1680 1095 1645 905 1365 730 1215 625
0.90 1650 1060 1430 865 1360 710 1210 595 1575 1035 1530 850 1250 705 1125 585
