Page 63 - Application Guide 04-2003 / Rooftop BALTIC Series - Page 63
arrangements drawings
1D DOWN SUPPLY AIR 3 FRESH AIR 5D DOWN HOT WATER ENTRY 8 EXTRACTION
1F FRONT SUPPLY AIR 4F
FRONT MAIN POWER ENTRY
6 GAS SUPPLY INLET 9 SMOKE OUTLET
2D DOWN RETURN AIR 4D
DOWN MAIN POWER ENTRY
7I OUTDOOR COIL INLET 10
CONDENSATE DRAINAGE
2F FRONT RETURN AIR 5F FRONT HOT WATER ENTRY 7O OUTDOOR COIL OUTLET
WITH OPTIONS ( including gas, electrical and hot water coil module )
020 025
▲
Fresh air
hood
option
BGK
BDK
