Page 79 - Application Guide 04-2003 / Rooftop BALTIC Series - Page 79
MULTIDIRECTIONAL HORIZONTAL ROOFCURB
030 035
BGK
BDK
1F'
Front supply air
2F
2F'
Front return air
1F
Front supply air
WARNING : ONLY ONE OF THE 4 FOLLOWINGS POSSIBILIES :
2F - 1F / 2F - 1F'
2F' - 1F / 2F' - 1F'
Front return air
2F' 2F 1F 2F'
1F
1F'
1F'
1F 2F'
2F
1F'
1F
2F'
2F
