Lennox CB30M-65

Page 10
CB29M & CB30M PARTS ARRANGEMENT
FIGURE 1
CONTROL BOX
ELECTRIC HEAT
SECTION
BLOWER
COMPARTMENT
COIL
HORIZONTAL
DRAIN PAN
EXPANSION
VALVE
BLOWER ACCESS
PANEL
COIL ACCESS
PANEL
FIGURE 2
CB29M and CB30M CONTROL BOX
TRANSFORMER
(T1)
SMALL ELECTRIC HEAT
KNOCK OUT FOR
2.5 – 15 kW
TERMINAL
STRIP (TB1)
TERMINAL
STRIP (TB1)
BRACKET FOR
TERMINAL STRIP
BLOWER
RELAY (K3)
LARGE ELECTRIC HEAT
KNOCK OUT FOR
20 – 30 kW
GROUNDING
LUGS
C
G
W1
W2
W3
R
TRANSFORMER (T26)
(575 VOLT ONLY)
DOOR INTERLOCK
SWITCH (S51)
