Lennox CBX32MV Series User Manual

Page 3
Specifications
General Data Model Number CBX32MV-048 CBX32MV-060 CBX32MV-068
Nominal cooling capacity − tons (kW)
4 (14.1) 5 (17.6) 5+ (17.6+)
Refrigerant
R−410A R−410A R−410A
Connections
in. (mm)
Suction (vapor) line − sweat
7/8 (22.2) 1-1/8 (28) 1-1/8 (28)
Liquid line − sweat
3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
Condensate drain (fpt)
(2) 3/4 (19) (2) 3/4 (19) (2) 3/4 (19)
Indoor
Coil
Net face area − ft.
2
(m
2
)
7.22 (0.67) 7.22 (0.67) 7.77 (0.72)
Tube outside diameter − in. (mm)
3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
Number of rows
3 3 3
Fins per inch (fins per m)
12 (472) 12 (472) 12 (472)
Blower Data
Wheel nominal diameter x width − in. (mm)
12 x 9 (305 x 229) 12 x 9 (305 x 229) 15 x 9 (381 x 229)
Motor output − hp (W)
1 (746) 1 (746) 1 (746)
Filters
1
Number and size − in.
(1) 20 x 24 x 1 (1) 20 x 24 x 1 (1) 20 x 25 x 1
mm
508 x 610 x 25 508 x 610 x 25 508 x 635 x 25
Shipping Data − 1 Package − lbs. (kg) 212 (96) 212 (96) 244 (111)
ELECTRICAL DATA
Voltage − phase − 60hz 208/230V−1ph
208/230V−1ph 208/230V−1ph
2
Maximum overcurrent protection (unit only) 20 20 20
Minimum circuit ampacity (unit only) 11 11 11
Optional CIRCUIT BREAKER KITS − Must Be Ordered Extra
Amperage 25 30 35 40 45 50 60
Single Phase 23M58 23M59 23M60 23M61 23M62 23M63 23M64
Three Phase − − − 23M65 − − − 23M66 23M67 23M68 23M69

Lennox CBX32MV Series Specifications

General

Refrigerant	R-410A
Cabinet	Galvanized Steel
Stages	Variable
Configuration	Upflow/Horizontal
Product Type	Air Handler
Series	CBX32MV
Nominal Cooling Capacity (BTU/h)	18, 000 - 60, 000
Airflow (CFM)	600 - 2, 000
Motor Type	ECM
Voltage	208/230V
Depth (in.)	21
Blower Motor	Variable Speed
Coil	Aluminum
