Lennox CBX32MV User Manual

Page 31
CBX32MV SERIES
EVENHEAT OPERATION
INPUTS OUTPUTS
Room Thermostat Demand
Target Discharge Air
Temperature Set at 85ºF
Target Discharge Air
Temperature Set at 100ºF
Target Discharge Air
Temperature Set at 115ºF/130ºF
Y1 Heat Pump First Stage Heat Pump First Stage
Heat Pump First + First Electric
Heat Section (H1)
Y1 + Y2
Heat Pump First and Second
Stage
Heat Pump First and Second Stage
+ First Electric Heat Section (H1)
Heat Pump First and Second Stage
+ First Electric Heat Section (H1) +
Second Electric Heat Section (H2)
if number of electric heater sec-
tions detected is more than two.
Y1 + W1 and/or W2
Heat Pump First Stage + First
Electric Heat Section (H1)
Heat Pump First Stage + First
Electric Heat Section + Second
Electric Heat Section (H2) if num-
ber of electric heater sections de-
tected is more than two.
Heat Pump First Stage + First
Electric Heat Section (H1) Second
Electric Heat Section (H2) if num-
ber of electric heater sections de-
tected is more than two.
Y1 and Y2 + W1 and/or W2
Heat Pump First and Second
Stage+ First Electric Heat Section
(H1)
Heat Pump First and Second Stage
+ First Electric Heat Section + Sec-
ond Electric Heat Section (H2) if
number of electric heater sections
detected is more than two.
Heat Pump First and Second Stage
+ First Electric Heat Section (H1)
Second Electric Heat Section (H2)
if number of electric heater sec-
tions detected is more than two.
W1 and/or W2 First Electric Heat Section (H1)
First Electric Heat Section (H1) +
Second Electric Heat Section (H2)
if number of electric heater sec-
tions detected is more than two.
First Electric Heat Section (H1) +
Second Electric Heat Section (H2)
if number of electric heater sec-
tions detected is more than two.
Heat pump first or second stage or electric heat demand will start the
Air Handler Control (AHC) indoor blower at CFM value based on
tables found in installation instructions.
Heat Pump and electric heat
demand?
Increase target discharge air temperature by 15Fº
Last room thermostat Heat
up− staging action
Timer delays for
120 seconds
Timer delays for 150
seconds
A
One Stage More than one stage
No
Ye s
Figure 25. EVENHEAT Operation (1 of 2)

Lennox CBX32MV Specifications

General

Refrigerant	R-410A
Efficiency	High efficiency
Model Number	CBX32MV
Category	Air Handlers
Motor Type	ECM
Voltage	208/230V
Blower Motor	Variable Speed
Cabinet	Painted Steel
Nominal Cooling Capacity	2 to 5 tons
Nominal Airflow	Up to 2000 CFM
Filter Type	Standard
Heating Options	Electric Heat
Cooling Options	Compatible with Lennox air conditioners
Sound Level	Quiet operation
