Lennox CHP20-060 User Manual

Page 12
BLOWER DATA CHA16 Cont.
CHA16-048 BLOWER PERFORMANCE
@ 460/575 VOLTS (With Down-Flow Air Openings)
External Static
Air Volume at Various Blower Speeds
External
Static
Pressure
High Medium Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s
0 0 2140 1010 1745 825 1175 555
.05 12 2120 1000 1730 815 1175 555
.10 25 2080 980 1720 810 1170 550
.15 37 2045 965 1710 805 1170 550
.20 50 2005 945 1695 800 1165 550
.25 62 1975 930 1680 795 1160 545
.30 75 1940 915 1665 785 1150 545
.40 100 1870 885 1625 765 1135 535
.50 125 1790 845 1580 745 1110 525
.60 150 1705 805 1515 715 1075 505
.70 175 1605 760 1430 675 1030 485
.75 185 1555 740 1375 650 1000 470
NOTE Ċ All air data is measured external to the unit with dry coil and without air filter.
CHA16-048 BLOWER PERFORMANCE
@ 460/575 VOLTS (With Horizontal Air Openings)
External Static
Air Volume at Various Blower Speeds
External
Static
Pressure
High Medium Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s
0 0 2160 1020 1815 855 1210 570
.05 12 2125 1005 1800 850 1210 570
.10 25 2095 990 1790 845 1200 565
.15 37 2060 970 1780 840 1200 565
.20 50 2025 955 1760 830 1195 565
.25 62 1990 940 1745 825 1190 560
.30 75 1955 925 1730 815 1185 560
.40 100 1885 890 1690 800 1170 550
.50 125 1805 850 1640 775 1140 540
.60 150 1715 810 1575 745 1105 520
.70 175 1615 760 1495 705 1065 505
.75 185 1560 735 1445 680 1040 490
NOTE Ċ All air data is measured external to the unit with dry coil and without air filter.
CHA16-060 BLOWER PERFORMANCE
@ 230 VOLTS (With DownĆFlow Air Openings)
External Static
Air Volume at Various Blower Speeds
External Static
Pressure
High
MediumĆ
High
Medium
MediumĆ
Low
Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s
0 0 2725 1285 2490 1175 2235 1055 1940 915 1620 765
.05 12 2695 1270 2435 1150 2210 1045 1930 910 1625 765
.10 25 2665 1260 2430 1145 2185 1030 1925 910 1625 765
.15 37 2635 1245 2415 1140 2160 1020 1910 900 1610 760
.20 50 2600 1225 2395 1130 2140 1010 1895 895 1590 750
.25 62 2555 1205 2365 1115 2130 1005 1880 885 1580 745
.30 75 2510 1185 2335 1100 2115 1000 1865 880 1565 740
.40 100 2445 1155 2275 1075 2060 970 1830 865 1540 725
.50 125 2385 1125 2230 1050 2005 945 1765 835 1505 710
.60 150 2285 1080 2140 1010 1940 915 1725 815 1455 685
.70 175 2210 1045 2075 980 1880 885 1660 785 1405 665
.75 185 2175 1025 2030 960 1845 870 1615 760 1370 645
NOTE Ċ For 208v unit operation, derate air volume by 7%. All air data is meaĆ
sured external to the unit with dry coil and without air filter.
CHA16-060 BLOWER PERFORMANCE
@ 230 VOLTS (With Horizontal Air Openings)
External Static
Air Volume at Various Blower Speeds
External Static
Pressure
High
MediumĆ
High
Medium
MediumĆ
Low
Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s
0 0 2850 1345 2530 1195 2255 1065 1970 930 1640 775
.05 12 2820 1330 2475 1170 2230 1050 1965 925 1645 775
.10 25 2790 1315 2475 1170 2205 1040 1955 925 1645 775
.15 37 2760 1300 2455 1160 2180 1030 1940 915 1630 770
.20 50 2725 1285 2435 1150 2160 1020 1925 910 1610 760
.25 62 2680 1265 2405 1135 2150 1015 1910 900 1600 755
.30 75 2630 1240 2375 1120 2135 1010 1895 895 1585 750
.40 100 2570 1215 2315 1090 2080 980 1860 880 1560 735
.50 125 2510 1185 2270 1070 2025 955 1795 845 1525 720
.60 150 2410 1135 2180 1030 1960 925 1755 830 1475 695
.70 175 2335 1100 2115 1000 1900 895 1690 800 1425 670
.75 185 2300 1085 2070 975 1865 880 1650 780 1390 655
NOTE Ċ For 208v unit operation, derate air volume by 7%. All air data is meaĆ
sured external to the unit with dry coil and without air filter.
CHA16-060 BLOWER PERFORMANCE
@ 460/575 VOLTS (With Down-Flow Air Openings)
External Static
Air Volume at Various Blower Speeds
External
Static
Pressure
High Medium Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s
0 0 2725 1285 2405 1135 1905 900
.05 12 2680 1265 2365 1115 1890 890
.10 25 2635 1245 2325 1095 1870 880
.15 37 2590 1220 2290 1080 1855 875
.20 50 2550 1205 2255 1065 1840 870
.25 62 2515 1185 2220 1050 1820 860
.30 75 2485 1175 2190 1035 1795 845
.40 100 2395 1130 2120 1000 1745 825
.50 125 2325 1095 2050 965 1680 795
.60 150 2235 1055 1970 930 1570 740
.70 175 2150 1015 1900 895 1560 735
.75 185 2100 990 1860 880 1515 715
NOTE Ċ All air data is measured external to the unit with dry coil and without air filter.
CHA16-060 BLOWER PERFORMANCE
@ 460/575 VOLTS (With Horizontal Air Openings)
External Static
Air Volume at Various Blower Speeds
External
Static
Pressure
High Medium Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s
0 0 2850 1345 2430 1145 1940 915
.05 12 2805 1325 2385 1125 1920 905
.10 25 2760 1300 2345 1105 1905 900
.15 37 2715 1280 2310 1090 1885 890
.20 50 2670 1260 2275 1075 1870 880
.25 62 2640 1245 2240 1055 1850 875
.30 75 2605 1230 2210 1045 1825 860
.40 100 2515 1185 2140 1010 1775 840
.50 125 2445 1155 2120 1000 1710 805
.60 150 2355 1110 1990 940 1600 755
.70 175 2270 1070 1920 905 1590 750
.75 185 2225 1050 1880 885 1545 730
NOTE - All air data is measured external to the unit with dry coil and without air filter.
