BLOWER DATA CHP16/20 Cont.
CHP16/20Ć036 BLOWER PERFORMANCE
460 VOLTS (With DownĆFlow Air Openings)
External Static
Air Volume at Various Blower Speeds
External
Static
Pressure
High Medium Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s
0 0 1560 735 1380 650 1070 505
.05 12 1555 735 1355 640 1075 505
.10 25 1540 725 1330 630 1080 510
.15 37 1510 715 1320 625 1070 505
.20 50 1475 695 1315 620 1060 500
.25 62 1450 685 1295 610 1040 490
.30 75 1430 675 1270 600 1025 485
.40 100 1360 640 1215 575 980 460
.50 125 1280 605 1145 540 925 435
.60 150 1185 560 1045 495 850 400
.70 175 1070 505 925 435 750 355
.75 185 990 465 860 405 680 320
NOTE Ċ All air data is measured external to the unit with dry coil and without air filter.
CHP16/20Ć036 BLOWER PERFORMANCE
460 VOLTS (With Horizontal Air Openings)
External Static
Air Volume at Various Blower Speeds
External
Static
Pressure
High Medium Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s
0 0 1665 785 1490 705 1080 510
.05 12 1640 775 1465 690 1080 510
.10 25 1610 760 1440 680 1080 510
.15 37 1585 750 1420 670 1075 505
.20 50 1555 735 1400 660 1070 505
.25 62 1525 720 1380 650 1060 500
.30 75 1495 705 1355 640 1050 495
.40 100 1435 675 1300 615 1015 480
.50 125 1365 645 1250 590 985 465
.60 150 1295 610 1180 555 935 440
.70 175 1205 570 1100 520 860 405
.75 185 1145 540 1060 500 800 380
NOTE Ċ All air data is measured external to the unit with dry coil and without air filter.
CHP20-042 CHP16/20Ć048 BLOWER PERFORMANCE
230 VOLTS (With Down-Flow Air Openings)
External Static
Air Volume at Various Blower Speeds
External Static
Pressure
High
MediumĆ
High
MediumĆ
Low
Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s cfm L/s
0 0 2015 950 1610 760 1425 670 1240 585
.05 12 2000 945 1595 755 1420 670 1235 585
.10 25 1980 935 1580 745 1415 670 1235 585
.15 37 1960 925 1575 745 1415 670 1230 580
.20 50 1935 915 1560 735 1405 665 1225 580
.25 62 1910 900 1540 725 1395 660 1215 575
.30 75 1885 890 1520 715 1385 655 1205 570
.40 100 1825 860 1485 700 1355 640 1185 560
.50 125 1760 830 1445 680 1315 620 1160 550
.60 150 1690 800 1395 660 1260 595 1130 535
.70 175 1615 760 1335 630 1190 560 1095 515
.75 185 1575 745 1300 615 1145 540 1065 505
NOTE Ċ For 208v unit operation, derate air volume by 7% All air data is measured
external to the unit with dry coil and without air filter.
CHP20-042 CHP16/20Ć048 BLOWER PERFORMANCE
230 VOLTS (With Horizontal Air Openings)
External Static
Air Volume at Various Blower Speeds
External Static
Pressure
High
MediumĆ
High
MediumĆ
Low
Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s cfm L/s
0 0 2075 980 1675 790 1445 680 1275 600
.05 12 2060 970 1660 785 1440 680 1270 600
.10 25 2040 965 1645 775 1435 675 1270 600
.15 37 2020 955 1635 770 1435 675 1265 595
.20 50 1995 940 1620 765 1425 670 1260 595
.25 62 1965 930 1600 755 1415 670 1250 590
.30 75 1940 915 1580 745 1405 665 1240 585
.40 100 1880 890 1545 730 1375 650 1220 575
.50 125 1815 855 1500 710 1335 630 1195 565
.60 150 1740 820 1450 685 1280 605 1165 550
.70 175 1655 780 1395 660 1210 570 1130 535
.75 185 1605 755 1365 645 1165 550 1110 525
NOTE Ċ For 208v unit operation, derate air volume by 7% All air data is measured
external to the unit with dry coil and without air filter.
CHP16/20Ć048 BLOWER PERFORMANCE
460 VOLTS (With DownĆFlow Air Openings)
External Static
Air Volume at Various Blower Speeds
External
Static
Pressure
High Medium Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s
0 0 2075 980 1650 780 1105 520
.05 12 2045 965 1635 770 1105 520
.10 25 2015 950 1625 765 1100 520
.15 37 1980 935 1615 760 1100 520
.20 50 1945 920 1600 755 1095 515
.25 62 1915 905 1585 750 1090 515
.30 75 1880 890 1570 740 1085 510
.40 100 1810 855 1535 725 1070 505
.50 125 1735 820 1490 705 1045 495
.60 150 1650 780 1430 675 1010 475
.70 175 1555 735 1355 640 965 455
.75 185 1500 710 1310 620 935 440
NOTE Ċ All air data is measured external to the unit with dry coil and without air filter.
CHP16/20Ć048 BLOWER PERFORMANCE
460 VOLTS (With Horizontal Air Openings)
External Static
Air Volume at Various Blower Speeds
External
Static
Pressure
High Medium Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s
0 0 2090 985 1755 830 1115 525
.05 12 2065 975 1740 820 1115 525
.10 25 2035 960 1720 810 1110 525
.15 37 2005 945 1705 805 1110 525
.20 50 1975 930 1685 795 1105 520
.25 62 1950 920 1675 790 1100 520
.30 75 1920 905 1650 780 1095 515
.40 100 1860 880 1600 755 1080 510
.50 125 1790 845 1555 735 1055 500
.60 150 1720 810 1495 705 1020 480
.70 175 1640 775 1425 670 975 460
.75 185 1595 755 1385 655 945 445
NOTE Ċ All air data is measured external to the unit with dry coil and without air filter.
