Lennox CLIMATIC 200 User Manual

10
ANALOGUE INPUTS
NOTE: When the leds on the
display flash alternatively
from one to the other, you
are on menu mode.
Probe value
Probe value
Probe value
Probe value
Probe value
Probe St1
Probe St2
Probe St3
Probe St6
Inlet water temperature.
Outlet water temperature.
Piping temperature/pression at circuit 1.
Piping temperature/pression at circuit 2 (ONLY MODEL
Climatic
®
400).
For every unit without anti-freeze the minimum outlet water temperature should be 5ºC.
For applications where the outlet water temperature is lower than 5ºC is necessary to use anti-freeze.
Probe St4
Outdoor temperature (with option Dynamic set point).
SET POINT
Probe status
MAIN DISPLAY
It shows:
Inlet water temperature
Active alarms
Press
Press
mode
on off
mode
on off
+
mode
on off
+
>2" <2"
