Lennox CLIMATIC series User Manual

• 61 •
50 Analog R 0.0 ~ 100.0
51 Analog R 0.0 ~ 100.0
52 Analog R -99.9 ~ 99.9
53 Analog R -99.9 ~ 99.9
54 Analog R -99.9 ~ 99.9
55 Analog R -99.9 ~ 99.9
56 Analog R 0.0 ~ 100.0
57 Analog R 0.0 ~ 100.0
58 Analog R 0.0 ~ 100.0
59 Analog R 0.0 ~ 100.0
60 Integer R 0 ~ 65536
61 Integer R 0 ~ 65536
62 Integer R 0 ~ 65536
63 Integer R 0 ~ 65536
64 Integer R 0 ~ 65536
65 Integer R 0 ~ 65536
66 Integer R 0 ~ 65536
67 Integer R 0 ~ 65536
68 Integer R 0 ~ 65536
69 Integer R 0 ~ 65536
70 Integer R 0 ~ 65536
71 Integer R 0 ~ 65536
72 Integer R 0 ~ 32767
73 -32768 ~ 32767
74 Integer R 0 ~ 65536
CLIMATIC RT_UNITARY-IOM-1508-E
BMS
@Address R/W DESCRIPTION MIN Fact. MAX
hot water coil, opening percentage calculated for the valve
humidifi er, power percentage calculated for the proportional signal
remote control, value of the signal, be-1 b1, temperature
remote control, value of the signal, be-1 b2, temperature
remote control, value of the signal, be-1 b3, temperature
remote control, value of the signal, be-1 b4, temperature
remote control, value of the signal, be-1 b1, humidity
remote control, value of the signal, be-1 b2, humidity
remote control, value of the signal, be-1 b3, humidity
remote control, value of the signal, be-1 b4, humidity
unit, count value (weight low) of operating time
unit, count value (weight high) of operating time
blower, count value (weight low) of operating time
blower, count value (weight high) of operating time
circuit 1 compressor 1, count value (weight low) of operating time
circuit 1 compressor 1, count value (weight high) of operating time
circuit 1 compressor 2, count value (weight low) of operating time
circuit 1 compressor 2, count value (weight high) of operating time
circuit 2 compressor 1, count value (weight low) of operating time
circuit 2 compressor 1, count value (weight high) of operating time
circuit 2 compressor 2, count value (weight low) of operating time
circuit 2 compressor 2, count value (weight high) of operating time
blower, calculated value of air fl ow
not used
Alarm, 1
bit.0 = (70) Real Time Clock
bit.1 = (71) BE.1, Communication Bus
bit.2 = (72) BE.2, Communication Bus
bit.3 = (9) Unit power supply
bit.4 = (81) Room Temperature, Probe
bit.5 = (82) Room Humidity, Sensor
bit.6 = (83) Outside Temperature, Probe
bit.7 = (85) Supply Temperature, Probe
bit.8 = (88) Return Temperature, Probe
bit.9 = (22) Supply Temperature, Too Low
bit.10 = (80) Air Flow, Sensor
bit.11 = (73) Blower, Inverter, Communication Bus
bit.12 = (1) Blower, Flow Switch Cut Off
bit.13 = (91) Blower, Fan
bit.14 = (92) Blower, Inverter
bit.15 = (99) Fire / Smoke, Detected
