Lennox CLIMATIC series User Manual

• 67 •
152 Integer R 0~1
153 Integer R 0~1
154 Integer R 0~1
155 Integer R 0~1
156 Integer R 0~1
157 Analog R/W 8,0 22,0 35,0
158 Analog R/W 3,0 12,0 68,0
159 Analog R/W 30,0 38,0 68,0
160 Analog R/W 0,0 26,0 30,0
161 Analog R/W 0,0 19,0 30,0
162 Analog R/W -20,0 -20,0 50,0
163 Analog R/W -20,0 26,0 50,0
164 Analog R/W -10,0 20,0 50,0
165 Analog R/W -10,0 12,0 50,0
166 Analog R/W -20,0 -20,0 50,0
167 Analog R/W -20,0 -20,0 50,0
168 Analog R/W -20,0 10,0 50,0
169 Integer R/W 003
170 Integer R/W 003
171 Analog R/W -20,0 10,0 50,0
172 Integer R/W 001
173 Integer R/W 001
174 Analog R/W 0,0 999,9 999,9
175 Integer R 0,0 ~ 1,0
176 Integer R 0,0 ~ 1,0
177 Integer R 0,0 ~ 6,5
178 Integer R 0,0 ~ 100,0
179 Integer R 0,0 ~ 100,0
180 Integer R/W 1124
181 Analog R 0,0 ~ 100,0
182 Integer R 0 ~ 65536
183 Integer R 0 ~ 65536
184 Integer R 0 ~ 65536
185 Integer R 0 ~ 65536
186 Integer R 0,0 ~ 100,0
187 Integer R/W 0 1000 2000
188 Integer R/W 0 1500 2000
CLIMATIC RT_UNITARY-IOM-1508-E
BMS
@Address R/W DESCRIPTION MIN Fact. MAX
remote control, state of the dry contact, be-1 id3
remote control, state of the dry contact, be-1 id4
control, state of cooling mode
control, state of dead zone
control, state of heating mode
economizer, temperature threshold for activation night refreshment function
control, low supply limit threshold in cooling mode
control, high supply limit threshold in heating mode
control, room temperature threshold for unloading cooling mode
control, room temperature threshold for unloading heating mode
economizer, outside lower temperature threshold for unloading frre-cooling
economizer, outside upper temperature threshold for unloading free-cooling
circuit, outside temperature threshold for unloading 50% in cooling mode
circuit, outside temperature threshold for unloading 100% in cooling mode
circuit, outside temperature threshold for unloading 50% in heating mode
circuit, outside temperature threshold for unloading 100% in heating mode
heaters, outside temperature threshold for unloading
1st heaters, bms night, set point for priority inversion starting
1st heaters, bms day, set point for priority inversion starting
1st heaters, outside temperature threshold for inversion starting
2nd heaters, bms night, set point for priority inversion starting
2nd heaters, bms day, set point for priority inversion starting
power meter, current threshold for unloaded 50% of compressors running
circuit 3 compressor 1, state
circuit 3, state of the reversing valve (heating mode)
clock, state of the schedule (zone.mode)
2nd heaters, power percentage calculated for the triac
hot water recovery, opening percentage calculated for the valve
master/slaves, setting the sub-bus
blower, speed percentage calculated for the inverter
control, count value (weight low) of operating time in cooling mode
control, count value (weight high) of operating time in cooling mode
control, count value (weight low) of operating time in heating mode
control, count value (weight high) of operating time in heating mode
cold water coil, opening percentage calculated for the valve
economizer, minimum threshold for air quality control
economizer, maximum threshold for air quality control

Lennox CLIMATIC series Specifications

General

Connectivity	Wi-Fi
Compatibility	Lennox HVAC systems
User Interface	Touchscreen
Remote Access	Yes, via app
Energy Management	Energy-saving modes
Display	Color
Programmability	7-day programmable
