Lennox eCOMFORT R32 GAC 035S

• 45 •
SPXX KGRL
DPXX WFIF
AVUB
GAC/GAH 065S-070S
GAC-H_065S_070S_H_R32_Z
GAC-H_065S_070S_S_R32_Z
Installation manual / eCOMFORT R32-MIL166E-0222 - 09/2022
STANDARD VERSION OR WITH HIGH PRESSURE EC FANS (HIPF)
UNIT WITH STANDARD AC FANS (SFAC)
All dimensions in mm
All dimensions in mm
Victaulic or welded
connection
Flange connection Flange connection
Victaulic or welded
connection
Flange connection Flange connection
Hydraulic module with single pump Flange connection
Hydraulic module with twin pum Water lter (supplied loose)
Rubber anti-vibration mounts
Controller
connection Ø 29
Controller
connection Ø 29
1.- GENERAL CHARACTERISTICS
1.9.- DIMENSIONS
