Lennox EL16XP1 Series User Manual

Page 3
Dimensions
ELECTRICAL
INLETS
SIDE VIEW
DISCHARGE AIR
VAPOR LINE
CONNECTION
LIQUID LINE
CONNECTION
A
B
C
4-1/4 (108)
4-3/4
(121)
1 (25)
2 (51)
END VIEW
TOP VIEW
VAPOR LINE
CONNECTION
LIQUID LINE
CONNECTION
UNIT SUPPORT
FEET
16-7/8
(429)
26-7/8
(683)
30-3/4 (781)
3-1/8
(79)
8-3/4
(222)
3-3/4 (95)
4-5/8
(117)
UNIT SUPPORT
FEET
EL16XP1-018 TO -030 BASE SECTION
(Medium Base)
EL16XP1-036 TO -060 BASE SECTION
(Large Base)
13-7/8
(352)
3-5/8
(92)
20-5/8
(524)
7-3/4
(197)
27-1/8
(689)
4-1/2
(114)
3-1/4
(83)
(Depth)
(Width)
Model No.
ABC
in. mm in.mmin. mm
EL16XP1-018 45 1143 30-1/2 77535889
EL16XP1-024 35 889 30-1/2 77535889
EL16XP1-030 35 889 30-1/2 77535889
EL16XP1-036 35 889 35-1/2 90239-1/21003
EL16XP1-042 45 1143 35-1/2 90239-1/21003
EL16XP1-048 45 1143 35-1/2 90239-1/21003
EL16XP1-060 45 1143 35-1/2 90239-1/21003
