Lennox EL195UHNE Series

Page 2
EL195UHNE Unit Dimensions - inches (mm)
AIR FLOW
23
(584)
(19)
3/4
(19)
1
Bottom Return
Air Opening
GAS PIPING INLET
(Right Side Only)
Side Return
Air Opening
(Either Side)
1
Bottom Return
Air Opening
EXHAUST AIR
OUTLET
ELECTRICAL
INLET
(Either Side)
SUPPLY AIR
OPENING
FRONT VIEW SIDE VIEW
TOP VIEW
A
B
9/16 (14)
C
3/4
27-3/4
(705)
19-7/16
(494)
23-1/2
(597)
1-1/2
(38)
6-1/2 (165)
(Either Side)
33
(838)
3-1/4
(83)
1-15/16 (49)
14
(356)
9/16
(14)
12-5/8
(321)
2
OPTIONAL
SIDE RETURN
AIR FILTER KIT
(Either Side)
16
(406)
14-3/4
(375)
2
OPTIONAL
SIDE RETURN
AIR FILTER KIT
(Either Side)
5/8
(16)
1
3-1/4
(83)
23-3/4
(603)
25
(635)
1-1/2 (38)
Front Panel
COMBUSTION
AIR INTAKE
1-7/8 (48)
CONDENSATE
TRAP CONNECTION
(Either Side)
INTAKE AIR
2-1/4
(57)
2-7/8
(73)
6-5/8
(168)
Not Used
2
Optional Side Return Air Filter Kit is not for use
with the Optional Return Air Base.
1
NOTE - 60C size units that require air volumes over
1800 cfm must have one of the following:
1. Single side return air and Optional Return Air Base
with transition that must accommodate required
20 x 25 x 1 inch (508 x 635 x 25 mm) air filter to
maintain proper velocity.
2. Bottom return air.
3. Return air from both sides.
4. Bottom and one side return air.
See Blower Performance Tables for additional information.
Model
A
in (mm)
B
in (mm)
C
in (mm)
EL195UH040NE36B
EL195UH060NE36B
17-1/2 (446) 16-3/8 (416) 16 (406)
EL195UH080NE48C
EL195UH100NE60C
21 (553) 19-7/8 (505) 19-1/2 (495)
