Lennox EL195UHNE Series User Manual

Page 2
SPECIFICATIONS
Gas
Heating
Performance
Model No. EL195UH040NE36B EL195UH060NE36B
AHRI Ref. No. 201834895 201834898
1
AFUE 95% 95%
Input - Btuh 40,000 60,000
Output - Btuh 39,000 58,000
Temperature rise range - °F 30 - 60 35 - 65
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
3.5 / N/A 3.5 / 4.0
High static - in. w.g. 0.5 0.5
Energy Star
®
Certied Yes Yes
Connections
in.
Intake / Exhaust Pipe (PVC) 2 / 2 2 / 2
Gas pipe size IPS 1/2 1/2
Condensate Drain Trap (PVC pipe) - i.d. 3/4 3/4
with furnished 90° street elbow 3/4 slip x 3/4 Mipt 3/4 slip x 3/4 Mipt
with eld supplied (PVC coupling) - o.d. 3/4 slip x 3/4 MPT 3/4 slip x 3/4 MPT
Indoor
Blower
Wheel nom. dia. x width - in. 10 x 8 10 x 8
Motor Type DC Brushless DC Brushless
Motor output - hp 1/2 1/2
Tons of add-on cooling 1 - 2 1.5 - 3
Air Volume Range - cfm 260 - 990 550 - 1380
Electrical Data Voltage 120 volts - 60 hertz - 1 phase
Blower motor full load amps 6.8 6.8
Maximum overcurrent protection 15 15
Shipping Data lbs. - 1 package 122 128
NOTE - Filters and provisions for mounting are not furnished and must be eld provided.
1
Annual Fuel Utilization E󰀩ciency based on DOE test procedures and according to FTC labeling regulations. Isolated combustion system rating for non-weatherized furnaces.
SPECIFICATIONS
Gas
Heating
Performance
Model No. EL195UH080NE48C EL195UH100NE60C
AHRI Ref. No. 201834896 201834897
1
AFUE 95% 95%
Input - Btuh 80,000 100,000
Output - Btuh 78,000 97,000
Temperature rise range - °F 40 - 70 45 - 75
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
3.5 / 4.0 3.5 / N/A
High static - in. w.g. 0.5 0.5
Energy Star
®
Certied Yes Yes
Connections
in.
Intake / Exhaust Pipe (PVC) 2 / 2 2 / 2
Gas pipe size IPS 1/2 1/2
Condensate Drain Trap (PVC pipe) - i.d. 3/4 3/4
with furnished 90° street elbow 3/4 slip x 3/4 Mipt 3/4 slip x 3/4 Mipt
with eld supplied (PVC coupling) - o.d. 3/4 slip x 3/4 MPT 3/4 slip x 3/4 MPT
Indoor
Blower
Wheel nom. dia. x width - in. 10 x 10 11-1/2 x 10
Motor Type DC Brushless DC Brushless
Motor output - hp 3/4 1
Tons of add-on cooling 2.5 - 4 3.5 - 5
Air Volume Range - cfm 760 - 1740 1260 - 2405
Electrical Data Voltage 120 volts - 60 hertz - 1 phase
Blower motor full load amps 8.4 10.9
Maximum overcurrent protection 15 15
Shipping Data lbs. - 1 package 148 157
NOTE - Filters and provisions for mounting are not furnished and must be eld provided.
1
Annual Fuel Utilization E󰀩ciency based on DOE test procedures and according to FTC labeling regulations. Isolated combustion system rating for non-weatherized furnaces.
