Page 48
BURNER, C.A.I ASSEMBLY &
HEAT EXCHANGER REMOVAL
Gas Valve
Primary Limit
Ignitor
Sensor
Gas Orifice
O Ring
High Temperature
Switch
(location)
Air Gas Plenum
Gaskets
Burner
Heat Exchanger
Burner Box
FIGURE 62
