Page 6
PARTS IDENTIFICATION
Ignition Control
Ignition Control
Gas Pipe Inlet
(right side only)
Intake Air Pipe
Exhaust Pipe
Heat Exchanger
Burner Assembly
Inlet Air Assembly
Rollout Switch
Gas Valve
Combustion
Air Inducer
FIGURE 1
