Lennox Elite XC13 - Unit Dimensions

Page 2
506120−01 03/10
Unit Dimensions − Inches (mm) and Parts Arrangement
OUTDOOR FAN
COMPRESSOR
HIGH PRESSURE
SWITCH
SUCTION LINE
SUCTION VALVE AND
GAUGE PORT/SUCTION
LINE CONNECTIONS
UNIT SUPPORT
FEET
8−1/2
(216)
XC13−018, −024, AND −030
BASE SECTIONS
8−3/4
(222)
5−1/2
(140)
9−1/2
(241)
8−1/4
(210)
13−1/2
(343)
ELECTRICAL
INLETS
SIDE VIEW
DISCHARGE AIR
SUCTION LINE
CONNECTION
LIQUID LINE
CONNECTION
4−1/4
(108)
4−3/4
(121)
1 (25)
2 (51)
SIDE VIEW
C
B
A
3−1/4
(83)
UNIT SUPPORT
FEET
XC13−036 TO −060 BASE SECTIONS
WITH ELONGATED LEGS
SUCTION LINE
CONNECTION
LIQUID LINE
CONNECTION
TOP VIEW
PARTS ARRANGEMENT
FILTER DRIER/
LIQUID LINE
CONNECTIONS
RUN
CAPACITOR
CONTACTOR
DISCHARGE
LINE
13−7/8
(352)
7−3/4
(197)
27−1/8
(689)
3−5/8
(92)
4−1/2 (114)
20−5/8
(524)
Model/Capacity A B C
XC13−018 27 (686) 27 (686) 28 (711)
XC13−024 27 (686) 27 (686) 28 (711)
XC13−030 31 (787) 27 (686) 28 (711)
XC13−036 31 (787) 27 (686) 28 (711)
XC13−042 31 (787) 31 (787) 35 (889)
XC13−048 39 (991) 31 (787) 35 (889)
XC13−060 35 (889) 31 (787) 35 (889)
