23
Cat.
No.
Description
H5952 #33 NG Main Burner Orifice
H5950 #49 LP Main Burner Orifice
H5843 2” Bottom Trim Piece
H5860 4 Piece Log Set
H5844 Air Control Burner Pan
H5842 Baffle Plate
H5519 Baffle Plate Holder Brackets
75145 Black Door w/Glass
H5660 Blower Power Cord (ref. form # 506033-04)
H5877 Blower Speed Control
H5996 Blower Speed Control And Housing (Includes 2 Rivets)
H5997 Blower w/Mounting Bracket
H5866 Brick Panel Set
H5934 Burner Tube
H5740 Cassette Assembly NG (For LP Installations, Also Order LP
Conversion Kit)
H5863 Volcanic Stone
H5985 Decorative Gold Bar On Lower Stove Body
H5986 Decorative Nickel Bar On Lower Stove Body
H5905 Door Rope (Per Foot) Order 8 Ft. for each door
75146 Gold Door w/Glass
H5875 Heat Sensed Blower Snap Switch
H3106 Left-hand Side Door (Mounting Brackets and Blower Speed
Control Installed)
H5881 LP Pilot Assembly (Includes Thermopile, Electrode And Wire)
H5930 LP Pilot Orifice
H5940 LP Regulator
H5744 Main Burner On/Off Rocker Switch
H5995 Main Burner On/Off Switch Wires
H5981 Main Door Decorative Gold Bars Each (2 Per Stove)
H5982 Main Door Decorative Nickel Bars Each (2 Per Stove)
H6000 Middle Bay Glass W/glass Tape Installed
REPLACEMENT PARTS - Firestar™ (GC3)
H5880 NG Pilot Assembly (Includes Thermopile, Electrode And Wire)
H5949 NG Pilot Orifice
H5939 NG Regulator
75147 Nickel Door W/glass
H5745 Piezo Igniter
H5999 Rheostat Wire
H5954 Robertshaw Main Gas Control Valve LP
H5937 Robertshaw Main Gas Control Valve NG
H5864 Rock Wool (embers)
H3107 Side Bay Glass W/glass Tape Installed Each (2 Per Stove)
H5998 Snap Switch Wire
H5882 Thermopile
75254 Top Trivet
H5993 Vent Safety Snap Switch W/bracket
H5994 Vent Safety Snap Switch Wires
H6837 Leveling Bolts
H6838 Door Latch
WARNING
Failure to position the parts in accordance with these
diagrams or failure to use only parts specifically
approved with this appliance may result in property
damage or personal injury.
AVERTISSEMENT
Risque de dommages ou de blessures si les pièces
ne sont pas installées conformément à ces schémas
et ou si des pièces autres que celles spécifiquement
approuvées avec cet appareil sont utilisées.
Contact an Authorized Lennox Hearth Products dealer to obtain any of
these parts. Never use substitute materials. Use of non-approved parts
can result in poor performance and safety hazards.
