Lennox G23Q3-50 Installation Instructions

Page 3
G23(X) Parts Arrangement
FIGURE 1
G23(X) UNIT WITH PANELS REMOVED
IGNITOR ASSEMBLY
MANIFOLD AND
GAS VALVE
GAS ORIFICE
DURALOK
TM
HEAT EXCHANGER
(Assembly)
FLUE
COLLECTOR BOX
TOP CAP GLASS FIBER
GASKET
ORIFICE PLATE
(FLUE TRANSITION
ASSEMBLY)
FLUE OUTLET
GLASS FIBER
GASKET
UPPER VEST
PANEL
FLAME
BAFFLES
(NO
x
units only)
RIGHT MANIFOLD BRACKET
ROLL-OUT BRACKET
MID VEST PANEL
PRIMARY LIMIT
MANIFOLD END
PLUG
ROLL-OUT SWITCH
LEFT MANIFOLD BRACKET
COMBUSTION
AIR BLOWER
PRIMARY LIMIT
ALTERNATE STYLE
BURNER ASSEMBLY
CONTROL BOX
SUPPLY AIR
OPENING
TOP CAP
BLOWER
ASSEMBLY
CAPACITOR
AND BRACKET
COMBUSTION
BLOWER
GASKET
FLUE BOX GLASS FIBER
GASKET
COMBUSTION
AIR PROVING
(PRESSURE) SWITCH
DOOR INTERLOCK SWITCH
SURELIGHT CONTROL BOARD
CONTROL
TRANSFORMER
CONTROL VOLTAGE
CIRCUIT BREAKER
