BLOWER DATA
G61MPV−60C−110 BLOWER PERFORMANCE (less filter)
Side Return Air with Optional RAB Return Air Base
0 through 0.80 in. w.g. External Static Pressure Range
ADJUST"
Switch
Positions
Speed Switch Positions
Second Stage HEAT" Speed − cfm Second Stage COOL" Speed − cfm
1
1
2 3 4 1 2 3
1
4
+ 1475 1670 1865 2070 1555 1685 1895 2130
1
NORM 1345 1500 1695 1865 1415 1540 1735 1930
 1180 1345 1510 1685 1245 1350 1545 1725
ADJUST"
Switch
Positions
First Stage HEAT" Speed − cfm First Stage COOL" Speed − cfm
1
1
2 3 4 1 2 3
1
4
+ 1330 1510 1695 1875 1085 1155 1310 1475
1
NORM 1195 1375 1550 1725 955 1050 1185 1335
 1080 1210 1370 1520 850 920 1070 1195
1
Factory default jumper setting.
NOTES − The effect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage
HEAT speed position.
First stage COOL (two−stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is approximately 38% of the same second stage COOL speed position − minimum 500 cfm.
Lennox Harmony IIIt Zone Control Applications − Minimum blower speed is 463 cfm.
G61MPV−60C−110 BLOWER MOTOR WATTS
Jumper Speed
Positions
Motor Watts @ Various External Static Pressures − in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
+" (Plus) SETTING (Adjust" Jumper at +" Setting)
HEAT"
Speed
Tap 1
170 195 225 255 290 320 350 380 410 215 250 285 320 355 390 425 455 490
Tap 2
230 265 305 345 380 415 445 480 515 315 355 400 445 480 510 540 575 605
Tap 3
350 385 420 460 495 525 560 595 630 460 490 525 555 605 655 690 730 770
Tap 4
450 490 535 580 610 640 680 720 760 590 630 680 725 785 840 880 915 955
COOL"
Speed
Tap 1
105 125 150 175 200 220 245 265 290 250 285 320 360 395 435 470 500 535
Tap 2
130
150 175 200 220 240 270 295 320 335 365 405 445 480 515 550 590 630
Tap 3
165 190 220 250 275 305 335 370 400 470 505 545 585 630 670 710 755 800
Tap 4
205 240 285 330 360 390 420 450 485 655 695 745 790 840 885 925 965 1005
NORM" (Normal) SETTING (Adjust" Jumper at NORM" Setting)
HEAT"
Speed
Tap 1
150 170 190 215 240 265 290 315 340 155 190 225 265 295 325 355 385 420
Tap 2
185
215 245 275 310 340 370 400 430 230 265 300 335 370 400 440 475 515
Tap 3
255 285 325 365 400 440 465 495 525 335 370 410 450 490 530 560 595 625
Tap 4
345 385 430 475 510 545 575 605 635 460 490 520 550 595 645 680 715 750
COOL"
Speed
Tap 1
75 90 115 135 160 185 205 225 250 190 220 255 290 325 360 395 430 460
Tap 2
100 120 145 165 185 205 230 255 280 250 285 325 360 390 420 455 485 520
Tap 3
135
155 175 200 230 260 280 305 330 355 395 435 475 510 545 580 620 660
Tap 4
170
195 225 255 290 320 350 375 405 475 515 565 610 655 705 745 785 825
−" (Minus) SETTING (Adjust" Jumper at −" Setting)
HEAT"
Speed
Tap 1
110 130 150 175 195 215 240 265 290 135 155 180 210 230 250 275 300 325
Tap 2
145 165 190 210 240 270 295 315 340 170 195 230 265 295 325 355 390 420
Tap 3
175
205 240 280 310 340 370 400 430 220 255 295 335 370 405 440 475 515
Tap 4
245 280 320 355 390 420 455 490 525 325 360 400 440 475 510 540 565 590
COOL"
Speed
Tap 1
55 70 90 110 135 155 175 195 220 150 170 200 225 255 285 315 340 370
Tap 2
65 80 105 130 150 170 195 215 240 165 195 230 265 300 330 360 390 420
Tap 3
100 125 150 180 200 220 240 260 280 240 280 320 360 400 435 470 505 540
Tap 4
140 160 180 200 230 260 285 305 330 350 385 420 455 500 540 575 610 645

Lennox G61MPV Specifications

General

Blower Type	Variable speed
Energy Star Certified	Yes
Gas Valve	Modulating
Fuel Type	Natural gas or propane
Ignition Type	Electronic
Heating Stages	2
Warranty	Limited Lifetime warranty on heat exchanger; 10-Year limited warranty on covered components
Heating Capacity	44, 000 to 132, 000 BTUH
