Lennox G61MPV User Manual

Page 17
BLOWER DATA
G61MPV−60C−111 BLOWER PERFORMANCE (less filter)
Bottom Return Air, Return Air from Both Sides or Return Air from Bottom and One Side.
0 through 1.00 in. w.g. External Static Pressure Range
ADJUST"
Switch
Positions
Speed Switch Positions
Second Stage HEAT" Speed − cfm Second Stage COOL" Speed − cfm
1
1
2 3 4 1 2 3
1
4
+ 1585 1810 1950 2170 1635 1750 1965 2195
1
NORM 1430 1635 1770 1970 1480 1605 1805 2015
 1265 1440 1600 1780 1290 1400 1605 1800
ADJUST"
Switch
Positions
First Stage HEAT" Speed − cfm First Stage COOL" Speed − cfm
1
1
2 3 4 1 2 3
1
4
+ 1450 1650 1790 1990 1120 1195 1380 1560
1
NORM 1295 1475 1630 1810 1020 1095 1225 1385
 1165 1330 1470 1635 900 970 1105 1245
1
Factory default jumper setting.
N/A − First and second stage HEAT positions shown cannot be used on this model.
NOTES − The effect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage
HEAT speed position.
First stage COOL (two−stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is approximately 38% of the same second stage COOL speed position − minimum 500 cfm.
Lennox Harmony IIIt Zone Control Applications − Minimum blower speed is 458 cfm.
G61MPV−60C−111 BLOWER MOTOR WATTS
Jumper Speed
Positions
Motor Watts @ Various External Static Pressures − in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
+" (Plus) SETTING (Adjust" Jumper at +" Setting)
HEAT"
Speed
Tap 1 210 235 270 300 335 365 395 425 455 275 305 345 380 415 445 475 505 535
Tap 2 265 305 345 385 425 465 505 545 585 350 395 440 485 530 570 605 645 685
Tap 3 425 460 490 525 560 590 615 645 675 575 605 640 670 700 730 765 795 800
Tap 4 540 580 625 665 710 745 780 815 850 730 770 805 845 885 925 965 1005 1015
COOL"
Speed
Tap 1 120 140 165 190 215 235 260 285 305 325 355 390 425 460 490 520 550 580
Tap 2 145 165 190 215 235 260 290 315 340 390 425 465 500 540 570 600 630 660
Tap 3 190 220 250 285 320 345 375 400 425 545 585 630 670 715 755 790 830 865
Tap 4 275 305 340 375 410 440 470 505 535 775 815 860 900 945 975 1010 1040 1060
NORM" (Normal) SETTING (Adjust" Jumper at NORM" Setting)
HEAT"
Speed
Tap 1 160 185 215 245 270 295 320 345 370 200 225 260 290 325 355 385 415 445
Tap 2 205 235 275 310 350 380 410 445 475 255 290 330 375 415 455 490 530 570
Tap 3 325 350 380 410 440 470 500 530 550 425 455 490 520 555 580 610 635 665
Tap 4 410 445 480 520 555 595 630 670 700 540 575 620 660 700 735 770 805 840
COOL"
Speed
Tap 1 90 110 135 160 185 200 220 235 260 225 255 290 325 360 390 425 455 485
Tap 2 105 130 155 180 205 230 250 270 290 295 325 360 395 430 465 495 525 560
Tap 3 145 165 195 220 250 275 295 320 350 435 465 505 540 575 605 635 665 700
Tap 4 190 220 250 280 315 345 370 400 430 590 625 665 705 745 790 830 875 905
−" (Minus) SETTING (Adjust" Jumper at −" Setting)
HEAT"
Speed
Tap 1 120 140 165 195 220 240 265 290 310 150 175 200 225 250 275 305 330 355
Tap 2 155 180 215 245 280 310 340 370 395 195 220 255 285 315 355 390 425 455
Tap 3 240 265 290 320 345 370 395 420 445 315 340 370 395 425 450 475 500 525
Tap 4 305 335 370 405 440 470 500 535 565 400 430 465 500 535 570 600 630 665
COOL"
Speed
Tap 1 75 90 110 130 150 170 190 215 230 165 190 220 245 275 305 330 360 390
Tap 2 85 105 125 145 165 190 210 230 255 200 230 260 295 325 355 385 415 445
Tap 3 115 135 160 185 205 230 250 270 295 305 335 370 405 440 470 505 540 570
Tap 4 155 175 205 230 260 285 310 335 360 425 460 495 530 570 595 625 655 690

Lennox G61MPV Specifications

General

Blower Type	Variable speed
Energy Star Certified	Yes
Gas Valve	Modulating
Fuel Type	Natural gas or propane
Ignition Type	Electronic
Heating Stages	2
Warranty	Limited Lifetime warranty on heat exchanger; 10-Year limited warranty on covered components
Heating Capacity	44, 000 to 132, 000 BTUH
