BLOWER DATA
G61MPV−60C−111 BLOWER PERFORMANCE (less filter)
Single Side Return Air − Air volumes in bold require field fabricated transition to accommodate 20 x 25 x 1 in. cleanable air filter in
order to maintain proper air velocity across the filter.
0 through 1.00 in. w.g. External Static Pressure Range
ADJUST"
Switch
Positions
Speed Switch Positions
Second Stage HEAT" Speed − cfm Second Stage COOL" Speed − cfm
1
1
2 3 4 1 2 3
1
4
+ 1525 1740 1905 2115 1585 1695 1880 2080
1
NORM 1370 1560 1720 1915 1430 1555 1725 1915
 1225 1395 1555 1730 1250 1355 1540 1710
ADJUST"
Switch
Positions
First Stage HEAT" Speed − cfm First Stage COOL" Speed − cfm
1
1
2 3 4 1 2 3
1
4
+ 1395 1590 1730 1920 1110 1175 1355 1520
1
NORM 1255 1430 1590 1765 1010 1075 1200 1350
 1130 1285 1430 1590 895 955 1085 1215
1
Factory default jumper setting.
N/A − First and second stage HEAT positions shown cannot be used on this model.
NOTES − The effect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage
HEAT speed position.
First stage COOL (two−stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is approximately 38% of the same second stage COOL speed position − minimum 500 cfm.
Lennox Harmony IIIt Zone Control Applications − Minimum blower speed is 458 cfm.
G61MPV−60C−111 BLOWER MOTOR WATTS
Jumper Speed
Positions
Motor Watts @ Various External Static Pressures − in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
+" (Plus) SETTING (Adjust" Jumper at +" Setting)
HEAT"
Speed
Tap 1 190 220 250 280 310 345 375 410 430 260 290 320 350 380 415 445 480 510
Tap 2 245 280 320 360 400 440 480 520 555 335 370 410 445 485 530 570 615 650
Tap 3 390 425 460 495 530 560 590 615 650 540 580 615 655 695 725 755 785 805
Tap 4 490 535 580 630 675 710 745 780 820 685 730 780 830 880 920 960 995 1015
COOL"
Speed
Tap 1 120 145 170 195 220 245 270 295 315 315 350 385 420 455 485 515 545 575
Tap 2 145 165 190 210 235 260 285 310 340 375 410 445 485 520 550 580 610 635
Tap 3 185 215 250 280 315 340 370 395 420 535 575 615 660 700 740 775 815 845
Tap 4 280 310 345 375 410 445 475 505 535 755 795 840 880 925 955 985 1015 1015
NORM" (Normal) SETTING (Adjust" Jumper at NORM" Setting)
HEAT"
Speed
Tap 1 155 175 200 230 255 275 300 320 350 180 205 240 270 300 330 360 390 420
Tap 2 200 225 260 290 325 355 385 410 450 230 265 305 345 385 425 460 500 535
Tap 3 315 340 375 405 440 460 485 510 535 390 425 460 495 530 560 590 615 645
Tap 4 395 435 475 515 555 585 615 645 675 495 535 580 625 670 705 745 780 815
COOL"
Speed
Tap 1 95 115 140 165 190 205 225 245 270 220 250 285 320 360 390 420 450 480
Tap 2 105 130 155 180 205 225 250 270 290 285 315 350 380 415 445 475 505 540
Tap 3 140 165 190 220 245 270 290 315 345 425 460 495 530 565 595 625 655 690
Tap 4 190 220 250 285 315 345 375 405 435 575 610 650 690 725 770 810 855 885
−" (Minus) SETTING (Adjust" Jumper at −" Setting)
HEAT"
Speed
Tap 1 115 135 160 185 210 230 250 270 300 145 165 190 215 235 265 290 315 345
Tap 2 150 175 205 235 265 295 320 250 385 185 210 245 275 305 335 370 405 440
Tap 3 235 260 285 310 335 360 380 405 435 295 325 350 380 410 440 470 495 515
Tap 4 300 330 360 390 420 455 485 515 550 375 410 445 485 520 555 590 630 655
COOL"
Speed
Tap 1 75 90 110 130 150 175 195 220 235 165 185 215 245 275 300 330 355 385
Tap 2 85 100 125 145 165 185 210 230 250 195 225 255 285 315 340 370 400 430
Tap 3 115 135 155 180 205 225 245 265 290 300 330 365 395 430 465 495 530 560
Tap 4 155 180 205 235 260 285 310 340 365 415 450 485 520 555 585 610 640 675

Lennox G61MPV Specifications

General

Blower Type	Variable speed
Energy Star Certified	Yes
Gas Valve	Modulating
Fuel Type	Natural gas or propane
Ignition Type	Electronic
Heating Stages	2
Warranty	Limited Lifetime warranty on heat exchanger; 10-Year limited warranty on covered components
Heating Capacity	44, 000 to 132, 000 BTUH
