BLOWER DATA
G61MPV−60D−135 BLOWER PERFORMANCE (less filter)
Bottom Return Air, Return Air from Both Sides or Return Air from Bottom and One Side.
0 through 0.80 in. w.g. External Static Pressure Range
ADJUST"
Switch
Positions
Speed Switch Positions
Second Stage HEAT" Speed − cfm Second Stage COOL" Speed − cfm
1
1
2 3 4 1 2 3
1
4
+ 1505 1705 1900 2110 1615 1730 1945 2190
1
NORM 1365 1550 1740 1920 1455 1580 1780 1985
 1225 1380 1545 1720 1305 1400 1600 1780
ADJUST"
Switch
Positions
First Stage HEAT" Speed − cfm First Stage COOL" Speed − cfm
1
1
2 3 4 1 2 3
1
4
+ 1385 1570 1760 1930 1135 1205 1365 1540
1
NORM 1250 1425 1595 1775 1025 1105 1235 1390
 1135 1265 1430 1585 915 985 1115 1235
1
Factory default jumper setting.
NOTES − The effect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage
HEAT speed position.
First stage COOL (two−stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is approximately 38% of the same second stage COOL speed position − minimum 500 cfm.
Lennox Harmony IIIt Zone Control Applications − Minimum blower speed is 470 cfm.
G61MPV−60D−135 BLOWER MOTOR WATTS
Jumper Speed
Positions
Motor Watts @ Various External Static Pressures − in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
+" (Plus) SETTING (Adjust" Jumper at +" Setting)
HEAT"
Speed
Tap 1
155 185 220 255 285 315 340 365 390 215 225 265 305 335 365 400 435 465
Tap 2
215 250 285 325 360 390 425 455 490 275 315 360 400 440 475 505 540 575
Tap 3
315 350 390 430 460 490 530 565 605 405 440 475 515 550 585 630 670 715
Tap 4
435 465 500 530 575 615 655 695 735 530 575 620 670 725 780 825 870 915
COOL"
Speed
Tap 1
95 120 145 170 190 215 240 265 290 250 285 320 360 390 420 450 485 515
Tap 2
115
135 160 185 210 235 260 290 315 290 330 375 420 455 490 525 565 605
Tap 3
145 175 215 250 275 300 330 355 385 425 465 505 550 590 635 670 710 750
Tap 4
205 240 280 320 350 380 410 445 480 615 655 700 745 800 855 900 940 980
NORM" (Normal) SETTING (Adjust" Jumper at NORM" Setting)
HEAT"
Speed
Tap 1
130 155 180 205 235 260 285 305 330 155 180 210 245 270 300 330 355 385
Tap 2
165
195 230 265 300 330 360 385 415 215 250 295 335 360 385 420 455 490
Tap 3
240 270 310 345 380 415 440 470 500 305 340 380 420 455 490 520 545 575
Tap 4
335 365 405 440 480 515 550 585 620 405 445 485 530 570 610 650 690 735
COOL"
Speed
Tap 1
80 95 115 135 160 190 210 230 255 185 215 245 280 310 335 370 400 430
Tap 2
90 115 140 165 190 215 230 250 265 230 260 295 335 370 405 435 470 500
Tap 3
130
150 170 195 225 255 275 300 320 315 355 400 445 480 515 555 590 625
Tap 4
150
180 220 255 285 315 345 375 405 445 485 530 580 625 670 705 740 775
−" (Minus) SETTING (Adjust" Jumper at −" Setting)
HEAT"
Speed
Tap 1
100 120 140 165 190 215 240 265 290 125 150 175 200 225 245 270 295 320
Tap 2
130 155 180 210 235 265 285 310 330 155 185 215 250 280 305 335 365 395
Tap 3
170
200 235 270 300 330 360 390 420 220 250 280 315 350 390 425 460 490
Tap 4
225 260 300 335 375 410 435 465 490 295 325 360 395 435 470 505 545 580
COOL"
Speed
Tap 1
65 80 100 120 140 160 180 195 215 145 170 195 225 250 280 305 330 355
Tap 2
70 90 110 130 155 175 200 220 240 160 190 225 255 285 315 345 380 415
Tap 3
95 120 145 170 190 215 235 250 270 245 280 315 355 385 415 445 480 515
Tap 4
135 155 175 200 220 245 270 300 325 325 365 405 445 485 520 550 580 610

Lennox G61MPV Specifications

General

Blower Type	Variable speed
Energy Star Certified	Yes
Gas Valve	Modulating
Fuel Type	Natural gas or propane
Ignition Type	Electronic
Heating Stages	2
Warranty	Limited Lifetime warranty on heat exchanger; 10-Year limited warranty on covered components
Heating Capacity	44, 000 to 132, 000 BTUH
