Page 21
BLOWER DATA
G61MPV−60D−135 BLOWER PERFORMANCE (less filter)
Single Side Return Air − Air volumes in bold require field fabricated transition to accommodate 20 x 25 x 1 in. cleanable air filter in
order to maintain proper air velocity across the filter.
0 through 0.80 in. w.g. External Static Pressure Range
ADJUST"
Switch
Positions
Speed Switch Positions
Second Stage HEAT" Speed − cfm Second Stage COOL" Speed − cfm
1
1
2 3 4 1 2 3
1
4
+ 1470 1650 1845 2040 1585 1705 1905 2130
1
NORM 1325 1495 1680 1865 1430 1545 1765 1975
 N/A 1335 1505 1670 1275 1370 1565 1755
ADJUST"
Switch
Positions
First Stage HEAT" Speed − cfm First Stage COOL" Speed − cfm
1
1
2 3 4 1 2 3
1
4
+ 1335 1510 1695 1870 1105 1180 1330 1500
1
NORM 1210 1370 1540 1710 990 1075 1210 1355
 N/A 1225 1375 1515 890 950 1085 1210
1
Factory default jumper setting.
N/A − First and second stage HEAT positions shown cannot be used on this model.
NOTES − The effect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage
HEAT speed position.
First stage COOL (two−stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is approximately 38% of the same second stage COOL speed position − minimum 500 cfm.
Lennox Harmony IIIt Zone Control Applications − Minimum blower speed is 470 cfm.
G61MPV−60D−135 BLOWER MOTOR WATTS
Jumper Speed
Positions
Motor Watts @ Various External Static Pressures − in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
+" (Plus) SETTING (Adjust" Jumper at +" Setting)
HEAT"
Speed
Tap 1
150 175 210 240 270 300 330 360 390 180 215 255 295 330 365 400 430 465
Tap 2
205 235 275 310 355 395 430 465 500 275 315 360 400 435 470 510 550 585
Tap 3
315
345 385 420 460 495 535 570 610 415 450 490 525 565 600 640 675 715
Tap 4
430 460 495 530 575 620 665 705 750 535 585 640 695 730 765 810 860 905
COOL"
Speed
Tap 1
90 110 140 170 195 220 240 265 290 230 265 310 355 390 425 460 490 525
Tap 2
105 130 165 195 215 235 260 290 315 285 330 380 430 455 485 525 565 605
Tap 3
150
175 205 235 270 300 330 360 385 425 465 515 560 605 645 685 730 770
Tap 4
195
230 270 305 340 375 410 445 480 605 650 695 740 800 855 900 945 985
NORM" (Normal) SETTING (Adjust" Jumper at NORM" Setting)
HEAT"
Speed
Tap 1
120 140 170 200 225 255 280 305 330 150 175 210 240 270 300 335 365 400
Tap 2
155 185 220 255 295 335 365 395 425 205 240 275 315 350 385 422 460 495
Tap 3
235
265 300 330 370 405 440 470 500 290 330 380 430 460 485 515 545 575
Tap 4
320 355 390 430 465 505 540 575 610 395 440 485 530 575 620 660 700 740
COOL"
Speed
Tap 1
70 90 115 135 165 190 210 230 245 170 200 235 265 305 345 380 420 455
Tap 2
80 100 130 160 185 210 230 255 275 245 270 305 335 370 410 440 470 505
Tap 3
120 140 170 195 225 255 280 305 330 350 385 420 455 495 530 570 610 645
Tap 4
145
175 215 250 280 315 345 375 410 455 500 555 605 645 680 725 770 810
−" (Minus) SETTING (Adjust" Jumper at −" Setting)
HEAT"
Speed
Tap 1
N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Tap 2
125 150 175 195 230 265 290 310 335 150 175 210 240 255 290 330 370 405
Tap 3
155 185 215 250 285 320 355 385 420 205 235 270 305 345 380 420 455 490
Tap 4
205
240 285 325 355 385 420 460 495 290 325 360 400 440 480 515 545 580
COOL"
Speed
Tap 1
60 75 95 115 135 150 175 195 220 140 160 185 205 240 280 305 335 360
Tap 2
60 75 100 125 150 175 195 215 235 145 180 215 250 290 325 355 385 420
Tap 3
90 110 140 165 190 215 235 255 270 230 265 305 345 380 420 450 480 510
Tap 4
120 140 170 195 225 255 275 300 325 330 365 405 445 485 525 560 595 635

Lennox G61MPV Specifications

General

Blower Type	Variable speed
Energy Star Certified	Yes
Gas Valve	Modulating
Fuel Type	Natural gas or propane
Ignition Type	Electronic
Heating Stages	2
Warranty	Limited Lifetime warranty on heat exchanger; 10-Year limited warranty on covered components
Heating Capacity	44, 000 to 132, 000 BTUH
