• 26 •
PE
A1
M1
XA1
Installation, operation and maintenance / INALTO-IOM-1809-E
Size 05 to 15
Pic. 38
EC MOTOR + LXTFZ01M CONTROLLER
1112
UNIT LIMIT
LXTFZ01M
LEGEND:
PE Earth (yellow/green)
A1 Electronic control
M1 Motor
XA1 Terminal board
Shielded and
twisted cable
2x0,50 mmq
Cross section area not indicated = 1,5 mmq
WIRING DIAGRAM
