• 27 •
PE
L
N
Com
I
II
III
A1
C1
M1
Installation, operation and maintenance / INALTO-IOM-1809-E
Sizes 25 & 28
LEGEND:
PE Earth (yellow/green)
L Phase
N Neutral
Com Common
I Minimum speed
II Medium speed
III Maximum speed
A1 Power chart
C1 Capacitor
M1 Motor
Pic. 39
EC MOTOR + LXTFZ01M CONTROLLER
UNIT LIMIT
LXTFZ01M
Shielded and
twisted cable
2x0,50 mmq
Cross section area not indicated = 1,5 mmq
1112
WIRING DIAGRAM
