INNOV@ ECFAN DMR -AGU-0912-E • 24 •
Tab. 12 DX unit - “dry cooler” water cooled - DMWDR / DMWUR
MODELS:
DM
WDR /
DM
WUR
0060
0080
0100
0110
0130
0160
0190
0205
Power supply V/Ph/Hz
400V / 3Ph + N + PE / 50Hz
Air flow m
3
/h
1785 2150 3530 3530 3700 5100 5100 5100
COMPRESSOR
Type
-
Scroll
Nominal current
(*)
A
3.1 4.0 4.8 5.5 6.8 8.5 9.4 11.3
FLA A
5 6 6 7 10 13 13 15
LRA A
24 32 40 46 50 66 74 101
Oil charge l
1.00 1.00 1.10 1.10 1.36 1.65 1.65 1.65
WATER TEMPERATURE IN/OUT 40/45 °C
(*)
Cooling capacity (24°C; 50% RH)
kW
5.3 7.0 8.9 10.0 11.7 15.5 17.8 19.7
Power consumption kW
1.7 2.2 2.6 3.1 3.7 4.6 5.3 6.1
Water flow
l/h
1205 1568 1966 2222 2625 3424 3936 4385
Water pressure drop kPa
5.79 9.58 9.82 7.48 10.29 8.87 11.59 14.10
FINNED COIL EVAPORAT
OR
Front surface m
2
0.27 0.27 0.45 0.45 0.45 0.53 0.53 0.53
Geometry -
25 x 21.65
Rows Nr.
3 4 3 3 3 4 5 5
Type of fins
-
Hydrophilic
Fin pitch mm
1.8
SHR -
0.98 0.95 1.00 1.00 0.92 1.00 0.93 0.89
FAN SECTION
Type of fans -
Radial - EC
Power supply V/Ph/Hz
400V / 3Ph / 50Hz
Fans
Nr.
1
Nominal current A
0.26 0.35 0.54 0.54 0.50 1.05 1.19 1.19
Power consumption W
163 215 337 337 310 652 743 743
AESP Pa
30
AESP (max. fan speed) Pa
550 531 473 473 453 174 144 144
FILTER SEC
TION
Filter efficiency
-
G3
Overall surface m
2
2.2 2.2 3.6 3.6 3.6 5.0 5.0 5.0
Fire resistance class -
1
ELECTRICAL HEATERS
Total heating capacity kW
1.6 3.2
Heaters Nr.
1 2
Material
-
Aluminium
HOT GAS REHEATING CO
IL
Heating capacity kW
5.1 5.5 9.0 9.0 9.1 10.3 10.3 10.3
Front surface m
2
0.22 0.37
HOT WATER REHEATING
COIL
Heating capacity (water 45/40°C)
kW
4.2 4.6 7.8 7.8 8.0 9.2 9.2 9.2
Front surface m
2
0.22 0.37
Water flow
m
3
/h
0.730 0.792 1.365 1.365 1.393 1.595 1.595 1.595
Water side pressure drop kPa
8.2 9.4 15.5 15.5 16.1 20.3 20.3 20.3
Valve pressure drop kPa
3.3 3.9 4.4 4.4 4.6 6.0 6.0 6.0
Internal volume dm
3
0.9 1.3
HUMIDIFIER
Max. theoretical capacity kg/h
2.80 3.17 4.45 5.22 5.01 10.09 6.90 6.50
Effective capacity
kg/h
3
Power consumption kW
2.25
SOUND LEVEL
Sound pressure level
(**)
dB(A)
46 48 48 49 51 52 53 53
DIMENSIONS
Heigh x Lenght x Depth mm
1875 x 600 x 600 1875 x 900 x 600
Unit weight kg
162 169 207 232 265 273 285 287
(*)
At our Dry cooler; air 35 ° C; 30% RH
(**)
At 1,5 meters height, 2 meters frontal distance in free field; down flow units (30 Pa AESP); nominal air flow
